Broadcom NetXtreme II SERIES User Manual

Specifications: Broadcom NetXtreme II® Network Adapter User Guide
file:///C|/Users/Nalina_N_S/Documents/NetXtremeII/English/specs.htm[9/5/2014 3:45:19 PM]
p/n 48V40
Brocade 58-1000023-01
p/n C4D08 - Force10 1m DAC
Amphenol 599700002
Amphenol 616740001
p/n 53HVN - Force10 3m DAC
Amphenol 599700006
Amphenol 616740003
p/n 5CN56 - Force10 5m DAC
Amphenol 599700004
Amphenol 616740005
Interface Specifications
Table 6: 10/100/1000BASE-T
Performance Specifications
Feature Specification
PCI Express Interface x4 link width
10/100/1000BASE-T 10/100/1000 Mbps
Table 7: 10GBASE-T Performance
Specifications
Feature Specification
PCI Express Interface x8 link width
10GBASE-T 10 Gbps
NIC Physical Characteristics
PCI
Table 8: NIC Physical Characteristics
NIC Type NIC Length NIC Width
BCM5708 PCI Express 14.7 cm (5.79 inches) 6.4 cm (2.52 inches)
BCM5709/BCM5716 PCI Express x4 low-profile 11.9 cm (4.7 inches) 6.9 cm (2.7 inches)
BCM57710/BCM57711/BCM57712 PCI Express x8 low profile 16.8 cm (6.6 inches) 5.1 cm (2.0 inches)
BCM57810S PCI Express x8 low profile 16.8 cm (6.6 inches) 6.5 cm (2.54 inches)
BCM957840A4006G PCI Express x8 Mezzanine Card 14.4 cm (5.66 inches) 11.1 cm (4.370 inches)
BCM957840A4007G PCI Express x8 Mezzanine Card 10.9 cm (4.28 inches) 7.5 cm (2.97 inches)
NIC Power Requirements
Table 9: BCM5708C NIC Power Requirements
Link NIC 3.3V Current Draw (A) NIC Power (W)
Idle (no link) 1.44 4.75
1 Gbit 1.97 6.50
100 Mbit 1.60 5.28
10 Mbit 1.62 5.35
Table 10: BCM5709C/BCM5716 NIC Power Requirements
Link NIC 3.3V Current Draw (A) NIC Power (W)
Idle (no link) 1.01 3.32
1 Gbit 1.43 4.71
100 Mbit 1.16 3.81
