Fiber optic modules
Table 17 in the chapter “Hardware Specifications”lists the types of fiber optic modules (SFPs and
XFPs) supported on Brocade FGS and FGS-STK devices.
Table 3 describes the output of the show media command for each media type.
Lnk or Act Bottom left On The link is up.
Off The link is down.
Blinking The port is transmitting or receiving traffic.
10 Gbps Port LEDs
Lnk Located beside the 10
Gbps port.
This is the top-most
LED.
On The port is connected.
Off No fiber port connection exists or the link is down.
Act Located beside the 10
Gbps port.
This is the
bottom-most LED.
On or
Blinking
Traffic is being transmitted or received on the
fiber port.
Off No traffic is being transmitted or received on the
fiber port.
POE Port LEDs
POE Located along the
bottom of the copper
ports
Left for upper port
Right for lower port
On (Green) The port is enabled, a power-consuming device
has been detected, and the module is supplying
power to the device.
Off The port is not providing in-line power.
Power Supply LEDs
Power Right-most LED
beneath the console
port
On The device is powered on and has enough power
to operate.
Off The device is not powered on, or has been
powered on but does not have sufficient power to
operate.
PS1 Left-most LED
beneath the console
port
On Power supply 1 is installed and is functioning
normally. Power supply 1 is located in the
right-hand bay (when you are facing the rear of the
device).
Off Power supply 1 is not installed or is not providing
power.
PS2 Middle LED beneath
the console port
On Power supply 2 is installed and is functioning
normally. Power supply 2 is located in the
left-hand bay (when you are facing the rear of the
device).
Off Power supply 2 is not installed or is not providing
power.
Stacking LEDs
TABLE 4 LEDs (Continued)
LED Position State Meaning
