Power supply specifications

DRAFT: BROCADE CONFIDENTIAL

Power supply consumption

Table 20 lists the maximum power supply consumption for each FastIron GS model.

Table 21 lists the maximum power supply consumption for each FastIron GS-STK model.

TABLE 20 Maximum Power Supply Consumption for FGS Models

Model Maximum Power

Consumption

FGS624

without uplink

with 2 CX4+iXFP

with 2 XFP+1XFP

with Combo+1XFP

48 W

63 W

67 W

65 W

FGS648

without uplink

with 2 CX4

with 2XFP

with Combo

94 W

102 W

106 W

104 W

FGS624 power drawn from outlet with 1 power supply

without uplink

with 2 CX4+1XFP

with 2XFP+1XFP

with Combo+1XFP

99 W

121 W

FGS648 power drawn from outlet with 1 power supply

without uplink

with 2 CX4

with 2XFP

with Combo

162 W

170 W

FGS624 power drawn from outlet with 2 power supplies

(PS efficiency goes down as load increases)

without uplink

with 2CX4+1XFP

with 2XFP+1XFP

with Combo+1XFP

127 W

161 W

FGS648 power drawn from outlet with 2 power supplies

(PS efficiency goes down as load decreases)

without uplink

with 2 CX4

with 2XFP

with Combo

192 W

204 W

TABLE 21 Maximum Power Supply Consumption for FGS-STK Models

Model Maximum Power

Consumption

FGS624-STK

with 2 CX4+1XFP 63 W

FGS648-STK

with 2 CX4 102 W
