22 Brocade FastIron GS and FastIron GS-STK Hardware Installation Guide
53-1001783-01
Installation precautions
2
DRAFT: BROCADE CONFIDENTIAL
CAUTION: Make sure you insert the power supply right-side up. It is possible to insert the supply
upside down, although the supply will not engage with the power backplane when upside down.
The power supply is right-side up when the power connector is on the left and the fan vent is on
the right.
Disconnect the power cord from all power sources to completely remove power from the device.
Make sure to choose the appropriate circuit device depending on the number of AC power
supplies installed in the device. The minimum current draw for the system is one AC power
supply.
Power supplies are hot swappable. However, Brocade recommends that you disconnect the
power supply from AC power before installing or removing the supply. The device can be running
while a power supply is being installed or removed, but the power supply itself should not be
connected to a power source. Otherwise, you could be injured or the power supply or other parts
of the device could be damaged.
Make sure that the power source circuits are properly grounded, then use the power cord
supplied with the device to connect it to the power source.
If the installation requires a different power cord than the one supplied with the device, make
sure you use a power cord displaying the mark of the safety agency that defines the regulations
for power cords in your country. The mark is your assurance that the power cord can be used
safely with the device.
