80 Brocade FastIron GS and FastIron GS-STK Hardware Installation Guide
53-1001783-01
Power supply specifications
6
DRAFT: BROCADE CONFIDENTIAL
FIGURE 52 DC Power Connector
4
FIGURE 53 Connecting DC Power Supply
1 Negative terminal screw
2 Positive terminal screw
3 48 RTN lead
4 -48 VDC lead
510 AWG wire
1Ground
2 Power supply locking screw
1
4
5
2
3
+
–
1
2
