Spare Tire and Wheel Mounted, Non-Marking Pnuematic:
Extra wheel with Non-Marking tire (385/65D22.5,16 ply) mounted, ready for
service. Net Weight: 350 pounds (159 kg)
Chassis:
Standard:
Cargo Deck:
Total Deck Area: 66 Square Feet (6 m
²). A maximum of 17,000 pounds (7700
kg) may be carried on the deck at creep speed when centered over or between
axles. Seven stake pockets are provided along edges of deck for 1-inch (25 mm)
pipe stakes. Stakes furnished. Cargo decks have skid resistant coating.
Lifting Rings:
Consists of four rings, one at each corner of the load deck, so sling can be
attached for lifting crane. Rings hang below deck surface when not in use.
Steps:
A step is located on each front corner providing access to deck area.
Outriggers:
Four hydraulic outriggers of box-beam construction. Independent control for each
outrigger. Hydraulic cylinders are equipped with direct-connected holding valves.
Pad dimensions: 11 inches (28 cm) x 16 inches (41 cm).
Pulling Eyes:
Two heavy eyes in front bumper provide for attachment of hook block so main
winch line can be used for pulling loads at or near floor level. Also for anchoring
tag lines from load on hook.
Tie Downs:
Two holes in the rear bumper (in conjunction with the pulling eyes) provide tie
down locations for transporting crane by truck or cargo container.
Accessory Storage Box
:
Consists of front deck plate with removable and lockable cover, and box for
carrying sheave block and other items. Storage box is 14 inches (35 cm) deep x
10½ inches (26 cm) wide x 36½ inches (93 cm) long.
Headlight and Taillight Grilles:
Consists of welded steel protective grilles for headlights and taillights. Easily
removable for replacing bulbs.
Chassis Options and Accessories:
Auxiliary Winch:
Optional worm gear winch, mounted behind front bumper, with a single lever
control at the operator's console. Hydraulic powered to provide bare drum line
pull of 10,000 pounds (4540 kg) at 33 feet per minute (10.2 m/min). Winch drum
is 3½ inches (90 mm) in diameter by 10 inches (250 mm) long. This winch
includes 115 feet (35 m) of 7/16-inch (11.1 mm) wire rope, hook and 4-way roller
guide. This rope can pull 5800 pounds (2630 kg) with a safety factor of 3.5:1.
Net Weight: 250 pounds (113 kg)
