3-10
IC-200 LUBRICATION SCHEDULE
ITEM DESCRIPTION
LUBE
50 250 500 1000 MONTHS NOTES
1 Accelerator Pedal MPG X 1 Zerk, Diesel
2 Anti-Two-Block Arm SIL X 2 Points - Oilcan
3 Axle Differential 424 X 12 Check @50, Change @12 Mo.
4 Axle Kingpins MPG X 4 Zerks
5 Axle Pivot Pin MPG X 1 Zerk
6 Axle Planetary Hubs 424 X 12 Check @50, Change @12 Mo.
7 Boom Cylinder Pins MPG X 2 Zerks
8 Boom Ext. Pins MPG X Wipe on.
9 Boom Hinge Pin MPG X 1 Zerk
10 Boom Rub Pads SIL X Spray or Wipe
11 Boom Chain EO X Spray or Wipe* IC-200-3
12 Boom Chain Sheaves MPG X 6 Zerks* IC-200-3
13 Brake Lever, Parking SIL X
14 Brake Linkages SIL X
15 Brake Reservoirs DTE X Check @50, Change When
Brakes are Serviced.
16 Cab Hinges & Latches SIL X
17 Control Valve Links SIL X
18 Drive Shaft Joints MPG X 3 Zerks 2WD, 6 Zerks 4WD
19
EO X X 3 Max. Check Daily, Change @50,
then at 250 or 3 Mo. Max.
20 Hook Swivel & Pin SIL X
21 Hydraulic Oil HO X X 12 Max. Check Daily, Change @1000
Hours or 12 Mo. Max.
22 Outrigger Legs MPG X Wipe on Legs.
23 Pump Shaft MPG X 2 Zerks
24 Rotation Bearing MPG X 1 Zerk*
25 Rotation Gearbox WGO Repack @ overhual
26 Rotation Gear Teeth OGG X Brush On.*
27 Rotation Pinion Bearing MPG X 1 Zerk*
28 Sheave Block MPG X 3 Zerks
29 Sheave Pins MPG X 2 Zerks Std, 2 Optional.
30 Steering Cyl. Ends MPG X 8 Zerks
31 Steering Link Ends MPG X 4 Zerks
32 Transmission, 4-Speed TPF X 12 Max. Check @250, Change @12 Mo.
33 Winch(es) MPL X 12 Check @250, Change @12 Mo.
34 Wire Rope 2-X X Spray, Brush or Soak.*
35 Wire Rope Retainers SIL X
*See Procedures in Manual
LUBE SYMBOLS
- Hydraulic Fluid - See Specs in Hyd. Sec.
- Multi-Purpose Gun Grease
- Mobil Fluid 424 or Equivalent
- Multi-Purpose Gear Lube, SAE 80W-90
- Mobil DTE 10, Excel 15 or Equivalent
- Open Gear Grease, Such as Mobilkote S
- (Do Not Use Brake Fluid)
- Silicone Lube, Aerosol with Concentrating Tube
- Engine Oil - See Specs in Engine Manual
- Worm Gear Oil, Exxon Cylesstic TK460
