1-15
Two-Part-Line Sheave Block:
Single sheave block for 2-part-line requirements. Block is specially designed to
reduce height, 23 inches (58 cm) from top to saddle of load hook. 10-inch (254
mm) O.D. sheave for 1/2-inch (13 mm) rope. Swivel hook with safety latch.
Includes bar on top to actuate trip arm of Anti-Two-Block device. Net Weight:
124 pounds (56 kg) for 2H and 200 pounds (91 kg) for 3H
Searcher Hook: (Nose Mount)
5000-pound capacity hook bracket is attached to the front of the boom tip with 4
pins through the boom extension attachment lugs. A hook with latch is pinned to
the tip of the bracket. Net Weight: 65 pounds (29 kg)
*** Specifications subject to change without notice ***
