Broderson IC-80-3J - Lubrication Schedule

3-9
IC-80 LUBRICATION SCHEDULE
LUBRICATION INTERVALS
ITEM DESCRIPTION
LUBE
50 250 500 1000 MONTHS NOTES
HOUR HOUR HOUR HOUR
1 Accelerator Pedal MPG X 1 Zerk (Diesel)
2 Anti-Two-Block Arm SIL X 2 Points - Oilcan
3 Axle Differential 424 X 12 Check @50, Change @12 Mo.
4 Axle Kingpins MPG X 8 Zerks
5 Axle Pivot Pin MPG X 1 Zerk Std., 2 Zerks 4x4
6 Axle Planetary Hubs 424 X 12 Check @50, Change @12 Mo.
7 Boom Cylinder Pins MPG X 2 Zerks
8 Boom Ext. Pins MPG X Wipe on
9 Boom Hinge Pin MPG X 1 Zerk
10 Boom Rub Pads SIL X Spray or Wipe
11 Brake Lever, Parking SIL X
12 Brake Linkages SIL X
13 Brake Reservoir DTE X Check @50, Change When
Brakes are Serviced
14 Cab Hinges & Latches SIL X
15 Control Valve Links SIL X
16 Drive Shaft Joints MPG X 3 Zerks Std., 6 Zerks 4x4
17 Engine Oil (Gas Engine) EO X X 3 Max. Check Daily, Change @50 then
@250 Hrs. or 3 Mo. Max.
18 Hook Swivel & Pin SIL X
19 Hydraulic Oil HO X X 12 Max. Check Daily, Change @1000
Hours or 12 Mo. Max.
20 Outrigger Legs MPG X Wipe on Legs
21 Pump Shaft MPG X 2 Zerks
22 Rotation Bearing MPG X 1 Zerk*
23 Rotation Gearbox WGO X 24 Check @250, Change @24 Mo.
24 Rotation Gear Teeth OGG X Brush On*
25 Sheave Block MPG X 2 Zerks
26 Sheave Pins MPG X 1 Zerk Std, 2 Boom Extension
27 Steering Rod Ends MPG X 6 Zerks Std, 4 Zerks 4x4
28 Transmission TPF X 12 Max. Check @50, Change @12 Mo.
29 Wheel Bearings, Rear WBG 12 Clean & Repack
30 Winch(es) MPL X 12 Check @250, Change @12 Mo.
31 Wire Rope 2-X X Spray, Brush or Soak*
32 Wire Rope Retainers SIL X
*See Procedures in Manual
LUBE SYMBOLS
TPF - ATF Type F MPG - Multi-Purpose Gun Grease
2-X - AMOVIS #2-
X
MPL - Multi-Purpose Gear Lube, SAE 80W-90
424 OGG - Open Gear Grease, Such as Mobilkote S
DTE SIL - Silicone Lube, Aerosol with Concentrating Tub
e
(Do not use brake fluid) WBG - Wheel Bearing Grease
EO - Engine Oil - See Specs in Engine Manual WGO - Worm Gear Oil, Exxon Cylesstic TK 460
HO - Hydraulic Fluid - See Specs in Hyd. Sec.
- Mobil Fluid 424 or Equivalen
t
- Mobil DTE 10 Excel 15 or Equivalen
t
