Brookfield CAP 2000+H User Manual

Brookeld Engineering Labs., Inc. Page 22 Manual No. M02-313E1209
Table III-5: Viscosity Standard Fluids for Calibration of CAP Spindles on Low Torque CAP 2000+
LOW
TORQUE
LOW
TEMP
LOW
TORQUE
HIGH
TEMP
Cone
Fluid
Part
Num-
ber
Nomi-
nal
Value
(cP)
Temp
(°C)
Sample
Size
(micro
liters)
Cone
Fluid
Part
Num-
ber
Nomi-
nal
Value
(cP)
Temp
(°C)
Sam-
ple
Size
(micro
liters)
CAP-S-01 CAP0L 57 25 67 CAP-S-01 CAP0H 57 60 67
CAP-S-02 CAP1L 89 25 38 CAP-S-02 CAP1H 89 60 38
CAP-S-03 CAP2L 177 25 24 CAP-S-03 CAP2H 177 60 24
CAP-S-04 CAP3L 354 25 124 CAP-S-04 CAP3H 354 60 124
CAP-S-05 CAP4L 708 25 67 CAP-S-05 CAP4H 708 60 67
CAP-S-06 CAP5L 1417 25 32 CAP-S-06 CAP5H 1417 60 32
CAP-S-07 CAP1L 89 25 1700 CAP-S-07 CAP1H 89 60 1700
CAP-S-08 CAP3L 354 25 400 CAP-S-08 CAP3H 354 60 400
CAP-S-09 CAP5L 1417 25 100 CAP-S-09 CAP5H 1417 60 100
CAP-S-10 CAP2L 177 25 170 CAP-S-10 CAP2H 177 60 170
Table III-6: Viscosity Standard Fluids for Calibration of CAP Spindles on High Torque CAP 2000+
HIGH
TORQUE
LOW
TEMP
HIGH
TORQUE
HIGH
TEMP
Cone
Fluid
Part
Num-
ber
Nomi-
nal
Value
(cP)
Temp
(°C)
Sample
Size
(micro
liters)
Cone
Fluid
Part
Num-
ber
Nomi-
nal
Value
(cP)
Temp
(°C)
Sam-
ple
Size
(micro
liters)
CAP-S-01 CAP1L 89 25 67 CAP-S-01 CAP1H 89 60 67
CAP-S-02 CAP2L 177 25 38 CAP-S-02 CAP2H 177 60 38
CAP-S-03 CAP3L 354 25 24 CAP-S-03 CAP3H 354 60 24
CAP-S-04 CAP4L 708 25 124 CAP-S-04 CAP4H 708 60 124
CAP-S-05 CAP5L 1,417 25 67 CAP-S-05 CAP5H 1,417 60 67
CAP-S-06 CAP6L 3,542 25 32 CAP-S-06 CAP6H 3,542 60 32
CAP-S-07 CAP7L 1,328 25 1700 CAP-S-07 CAP7H 1,328 60 1700
CAP-S-08 CAP8L 5,313 25 400 CAP-S-08 CAP8H 5,313 60 400
CAP-S-09 CAP9L 21,250 25 100 CAP-S-09 CAP9H 21,250 60 100
CAP-S-10 CAP10L 236 25 170 CAP-S-10 CAP10H 236 60 170
III.4 Cone Calibration
A special feature of the CAP Series Viscometers allows the user to perform a cone calibration
using Viscosity Standard Fluids. This eld calibration will accommodate any wear on the tip
of the cone which may result from contact with the plate. This also allows the user to purchase
a new cone spindle and perform the calibration in your plant
