Models 5800-S
Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
47
ENHANCEM ENTS
A STANDARD RESPONSE:< 1 SEC (5850/51) < 3 SEC (5853) [1].
B FAST RESPONSE (SPECIFY VALUES .... SEC.) [1]
C LINEAR RAMP (SPECIFY VALUES ....%/SEC.) [1]
D FLOW OUTPUT DAMPING (SPECIFY VALUES .... SEC.) [1]
CALIBRATION
0 UNCALIBRATED
1 STANDA RD CALIBRATION INCLUDED
2 STORAGE OF MULTIPLE CAL. CURVES; ADD PER A VAILABLE
CALIBRATION GA S
9 SPECIFY
POWER SUPPLY INPUT
A± 15 Vdc
B + 24 Vdc = (Standard selection)
C + 15 Vdc only
Z SPECIFY
AREA CLASSIFICATION
1 SAFE AREA
2 CERTIFIED FOR USE IN ZONE 2
9 SPECIFY
5850S/BC 1H A 1 A B3 C A 1 B 1 = TYPICAL MODEL NUMBER
BROOKS SMART MASS FLOW PRODUCTS
SMART MASS FLOW METERS / CONTROLLERS
NOTES:
1.
ENHANCEMENTS
PLEASE FILL IN THE REQUESTED SPECIFICATIONS WHEN YOU HAVE DESCRIBED THE ENHANCEMENTS.
Standard response time of the flow output signal: Model 5850/51 and 5860/60, standard 1 sec. or on request better
than 0.2 sec. Model 5853/63, standard 3 sec. or on request better than 1 sec. Model 5864, 3 sec.
Standard settling time for controllers: Model 5850/51, standard 1 sec. or on request better than 0.2 sec.
Model 5853, standard 3 sec. or on request better than 1 sec. (to within 2%full scale of final value)
2.
AREA SAFETY CLASSIFICATION
A "SPECIAL" CABLE CONNECTOR IS REQUIRED FOR ZONE 2 CERTIFICATION REQUIREMENTS.
THIS WILL BE SUPPLIED WHEN YOU HAVE SELECTED THE INTERCONNECTING CABLE. IF THE CUSTOMER
MAKES HIS OWN CABLE SET; YOU ALWAYS HAVE TO SELECT POSITION B - "MATING CONNECTOR ONLY".
Appendix E
