Brooks 5850 S - Page 47

Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
Models 5800-S
46
VALVE TYPE
0 METER ONLY (NO VALVE)
1 NORMALLY CLOSED (5850/51 SERIES)
2 NORMALLY CLOSED (PRESS.DIFF. >2BA R. 5853 SERIES)
3 NORMALLY CLOSED (PRESS.DIFF. <2BA R. 5853 SERIES)
4 NORMALLY OPENED (5850 ONLY)
5 NORMALLY CLOSED, 5850 SERIES, 300 BAR
9 SPECIFY
ELECTRICAL INPUT/OUTPUT
INPUT OUTPUT
A 0-5Vdc 0-5 Vdc & 0-20mA (INCL. RS 232, 9600 BDS)
B 4-20mA 4-20 mA & 1-5Vdc (INCL. RS 232, 9600 BDS)
C 0-20 mA 0-20mA & 0-5Vdc (INCL. RS 232, 9600 BDS)
D 1-5Vdc 1-5 Vdc & 4-20mA (INCL. RS 232, 9600 BDS)
E DIG. COMM. DIG. COMM. + 0 - 5 V dc
F DIG. COMM. DIG. COMM. + 4 - 20 mA
G DIG. COMM. DIG. COMM. + 0 - 20 mA
H DIG. COMM. DIG. COMM. + 1 - 5 V dc
I DIG. COMM. DIGITA L COMMUNICA TION (ONLY)
Z SPECIFY
COM M UNICATION / BAUDRATE
A 0 NONE (Communication w ill be possible via RS/232 and 9600 baud)
B* RS232
C* RS485
D 0 PROFIBUS-DP (PNO CERTIFIED, 831-A-023 and 541-C-068-AAG)
E 0 PROFIBUS-DP (not CERTIFIED, 831-A-021 and 541-C-062-AAG)
F* CA RDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICA TION)
G* CA RDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICA TION) RS-232
H* CARDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICA TION) RS-485
*1 38400 Baud
*2 19200
*3 9600
*4 7200
*5 4800
*6 3600
*7 2400 * BOTH HAVE TO BE SPECIFIED
*8 1200
INTERCONNECTION CABLE
ANO CABLE
B MATING CONNECTOR ONLY
C 3m ROUND CABLE
D 6m ROUND CABLE
E 3m ROUND CABLE INCLUDING COMMUNICA TION CABL
E
F 6m ROUND CABLE INCLUDING COMMUNICA TION CABL
E
Z SPECIFY
Appendix E
