Models 5800-S
Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
45
MECHANICAL CONNECTIONS
1A WITHOUT ADAPTORS (9/16"-18" UNF) (ONLY FOR 5850/60/51/61/53/63)
1B 1/4" TUBE COMPRESSION FITTINGS (ONLY FOR 5850/60/51/61)
1C 1/8" TUBE COMPRESSION FITTINGS (ONLY FOR 5850/60/51/61)
1D 3/8" TUBE COMPRESSION FITTINGS (ONLY FOR 5851/61)
1E 1/4" VCR (ONLY FOR 5850/60/51/61)
1F 1/4" VCO (ONLY FOR 5850/60/51/61)
1G 1/4" NPT (ONLY FOR 5850/60/51/61)
1H 6mm TUBE COMPRESSION FITTINGS (ONLY FOR 5850/60/51/61)
1J 10mm TUBE COMPRESSION FITTINGS (ONLY FOR 5850/60/51/61)
1K 1/4" BSP (F) (ONLY FOR 5850/60/51/61)
1Y ½" BSP (F) (ONLY FOR 5853/63)
1Z 1" BSP (F) (ONLY FOR 5853/63)
2A 1 1/16" - 12SAE/MS (ONLY FOR 5853/63)
2B ½" TUBE COMPRESSION FITTINGS (ONLY FOR 5850/60/51/61/53/63)
2C 3/4" TUBE COMPRESSION FITTINGS (ONLY FOR 5853/63)
2D 1" TUBE COMPRESSION FITTINGS (ONLY FOR 5853/63)
2E ½" NPT(F) (ONLY FOR 5853/63)
2F 1" NPT(F) (ONLY FOR 5853/63)
2G 1½" NPT(F) (SEE OPTION "E") (ONLY FOR 5853/63/64)
2H ½" VCO (200 ln/min. max.) (ONLY FOR 5850/60/51/61/53/63)
2J 3/4" VCO (ONLY FOR 5853/63)
2K ½" VCR (200 ln/min. max.) (ONLY FOR 5850/60/51/61/53/63)
2L DIN DN15PN40 (ONLY FOR 5853/63)
2M DIN DN25PN40 (ONLY FOR 5853/63)
2N DIN DN40PN40 (ONLY FOR 5853/63)
2O DIN DN50PN40 (ONLY FOR 5853/63)
2P ANSI ½" 150 LBS (ONLY FOR 5853/63)
2R ANSI ½" 300 LBS (ONLY FOR 5853/63)
2S ANSI 1" 150 LBS (ONLY FOR 5853/63)
2T ANSI 1" 300 LBS (ONLY FOR 5853/63)
2U ANSI 1½
"
150 LBS (ONLY FOR 5853/63)
2V ANSI 1½
"
300 LBS (ONLY FOR 5853/63)
2W ANSI 2" 150 LBS (ONLY FOR 5853/63)
2X ANSI 2" 300 LBS (ONLY FOR 5853/63)
2Y 1" VCO (ONLY FOR 5853/63)
2Z 3/4" VCR (ONLY FOR 5853/63)
9Z SPECIFY
O-RING/VALVE SEAT M ATERIAL
AVITON
B BUNA (NOT FOR 5853 see Options 3, " I ")
C PTFE/KALREZ (KALREZ SENSOR O-RINGS & VALVE SEAT) (NOT FOR 5853/63)
D KALREZ (NOT FOR 5853/63 see Options 3, " I ")
E PTFE O-RINGS / EPDM VALVE SEAT (Teflon Diaphragm for 5853)
M KA LREZ O-RINGS / METAL VALVE SEA T (NOT FOR 5853/63)
Z SPECIFY
Appendix E
