Home > Security > Send an Email Securely > Configure Email Sending Using Web Based Management
Configure Email Sending Using Web Based Management
Related Models: ADS-3300W
We recommend using Web Based Management to configure secured email sending with user authentication,
or email sending using SSL/TLS.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network > Network > Protocol.
Start from , if the navigation menu is not shown on the left side of the screen.
5. In the SMTP field, click Advanced Settings and make sure the status of SMTP is Enabled.
6. Configure the SMTP settings.
Confirm that the email settings are correct after configuration by sending a test email.
If you do not know the SMTP server settings, contact your network administrator or Internet Service
Provider (ISP).
7. When finished, click Submit.
8. Follow the instructions in the dialog box to test the current settings.
Related Information
Send an Email Securely
Related Topics:
Access Web Based Management
167

Table of Contents

Other manuals for Brother ADS-3100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother ADS-3100 and is the answer not in the manual?

Brother ADS-3100 Specifications

General IconGeneral
Color scanningYes
Input color depth48 bit
Maximum scan size355.6 x 215.9 mm
Output color depth24 bit
Output grayscale depth8 bit
Enhanced scan resolution1200 x 1200 DPI
ADF scan speed (color, A4)40 ppm
Optical scanning resolution600 x 600 DPI
Duplex ADF scan speed (color, A4)80 ipm
Sensor typeDual CIS
Internal memory512 MB
Scan file formatsJPEG, PDF, TIFF
Daily duty cycle (max)6000 pages
Maximum scan width215.9 mm
Maximum scan length5000 mm
Card thickness (max)1.32 mm
Media thickness (min)0.08 mm
Paper tray media weight40 - 200 g/m²
Scanning media types supportedBusiness Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper sizeA4
Control typeButtons
Product colorBlack, White
Built-in displayNo
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
Auto document feeder (ADF) input capacity60 sheets
Package width391 mm
Package height320 mm
Package weight3310 g
Input voltage100-240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (off)0.1 W
Power consumption (sleep)1.4 W
Power consumption (standby)5.4 W
Power consumption (typical)23 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth215 mm
Width299 mm
Height190 mm
Weight2600 g
