1. SPECIFICATIONS
1
BAS-311G, BAS-326G
1. SPECIFICATIONS
Sewing machine Lock stitch, pattern tacking sewing machine (with large shuttle hook)
Stitch formation Single needle lock stitch
Max. sewing speed 2,700 rpm
Sewing area (XxY) BAS-311G: Max. 130 x 100 mm, BAS-326G: Max. 220 x 100 mm
Feed mechanism Intermittent feed, pulse motor drive
Stitch length
0.05 − 12.7 mm
No. of stitches 500,000-stitch internal memory (*)
Maximum no. of stitches 20,000 stitches (per program)
No. of sewing data items
that can be stored
Internal memory: 512 (*), CF card: 900
Work clamp lift method
Solenoid specifications: Pulse motor drive method
Pneumatic specifications: Pneumatic method
Work clamp height Solenoid specifications: Max. 25 mm, pneumatic specifications: Max. 30 mm
2-step work clamp
Solenoid specifications: Integrated-type work clamp
Pneumatic specifications: Separate-type work clamp
Intermittent presser foot lift
amount
22 mm
Intermittent stroke
2 − 4.5 mm, 4.5 − 10 mm or 0 (Default setting 3 mm)
Rotary hook Double-capacity shuttle hook (standard shuttle hook sold separately)
Wiper device Standard equipment
Thread trimmer Standard equipment
Data storage method
Internal memory (Flash memory), CF card (32, 64, 128, 256 MB)
[Option] 3.5 floppy disk 2HD/1.44MB, 2DD
User programs 50
Cycle programs 9
Motor 550 W AC servo motor
Weights
Machine head approx. 88 kg, operation panel approx. 0.6 kg
Control box 14.2 − 16.2 kg (Differs depending on destination)
Power supply Single-phase 100 V/220 V, Three-phase 200 V/220 V/380 V/400 V 400 VA
Air pressure 0.5 MPa 1.8 l/min.
* The number of data items and stitches that can be stored will vary depending on the number of stitches in each program.
