J. / Thread trimmer mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA3301101 1 THREAD TRIMMER CAM
2 S23651001 2 SET SCREW SOCKET (FT) M6X6
3 SA4798001 1 SETTING PLATE SOLENOID
4 SA5135101 1 THREAD TRIMMER SOLENOID
5 017400802 2
BOLT M4X8
6 028040246 2
WASHER SPRING 2-4
7 026040236 2
WASHER PLAIN M 4
8 SA3307001 1
9 012400436 1 SET SCREW SOCKET (FT) M4X4
10 154599000 1 SOLENOID CUSHION
11 S02652001 1
BAND 1M
13 S55484002 2
BOLT SOCKET (S/P WASHER) M5X10
14 SA4799001 1
SHOULDER SCREW, 7-3
16 SA3309101 1
17 SA3310001 1 COLLAR, TR-TRIMMER
18 SA3311001 1
COLLAR SHAFT
19 S46903001 1
SET SCREW, M4X5
20 048040342 1 RETAINING RING E4
21 SA3315001 1 THREAD TRIMMER ROD
23 021060106 2 NUT 1 M6
24 S32462001 1
SHOULDER SCREW, B; M6
25 021060306 1 NUT 3 M6
26 S23651001 1 SET SCREW SOCKET (FT) M6X6
27 231071001 1 BUSH, 8X15
28 SA3312201 1
GUIDE SHAFT
29 SA3313101 1
SPRING, COMPRESSION
30 154596000 1
CUSHION
31 S32462001 1
SHOULDER SCREW, B; M6
32 021060306 1 NUT 3 M6
33 S25475101 1
SET SCREW, M6X19
34 021060106 1 NUT 1 M6
35 SA4546001 1
THREAD TRIMMER LEVER H
37 SA8652001 1
38 SA8654001 1 THREAD TRIMMER ROD H
39 S32465101 2
40 021060106 2 NUT 1 M6
41 S32462001 2
SHOULDER SCREW, B; M6
42 021060306 2 NUT 3 M6
43 SA3319101 1
SHAFT TR-TRIMMER LEVER
44 SA4545001 2
RETAINING RING EXTERNAL C8
46 012060636 2 SET SCREW SOCKET (FT) M6X6
47 SA8655001 1
SPRING, EXTENSION
49 018501236 2
BOLT SOCKET M5X12
50 028050246 2
WASHER SPRING 2-5
51 146354002 2
WASHER, PLAIN 5
52 SA8656001 1
SHAFT MOVABLE KNIFE LEVE
54 012060636 2 SET SCREW SOCKET (FT) M6X6
55 SA8658101 1 M-KNIFE CONNECTING PLATE
56 SA4354001 1
SHOULDER SCREW, 6-1.8
57 SA5157101 1 NEEDLE PLATE
58 SA6596001 1 MOVABLE KNIFE SET F
59 SA4518001 1
MOVABLE KNIFE SHOULDER SCRE
61 S00705001 1 MOVABLE KNIFE COLLA
M-KNIFE SPACER T0.2
62 SA3334001 1
M-KNIFE SPACER T0.3
BAS-342G-403
