Brother BAS-342G Parts Book

52
T. 󱿐󰦝󲏱 / Foot switch pedal mechanism
REF.NO CODE Q'TY  NAME OF PARTS RM
1 SA6038001 1 󲨪󳉈󳉏󳈱󳈠󳈤󲩋󲩏󳈋󳈻 2-PEDAL FOOT SWITCH, SW ASS
Y
2 S38168001 1 󳇾󳈠󳈓󳉂󳈋
󳈬
󳈩 SPRING, COMPRESSION 10X30
3 S38170001 2 󳈱󳈠󳈤󳈶
󳈜
󳉇
󳈬
󳈩 FOOT PEDAL SPRING
4 S36260000 3 󳈕󳈀󳈠󳈝󲩎󲩐
󳈰
󳉏
󳈸
󳈛󳉏 PIN BUTTON MICRO SWITCH, VX
5 S38174000 2 󳈱󳈠󳈤󳈶
󳈜
󳉇 FOOT PEDAL
6 S38175001 2
󳈶
󳈜
󳉇󳈷
󳈐
󳈀󳈛 PROTECTION PLATE, PEDAL
7 S38176101 2 󳈕󳈀󳈠󳈝󳈆󳈗󳈄
󳈬
󳈩 SPRING, PLATE
BAS-342G-651
