56
V.
/ Programmer
REF.NO
CODE
Q'TY
NAME OF PARTS
RM
1
SA5164001
1
LCD MODULE
2
SA5165001
1
LCD INVERTE
R
3
SA5166001
1
INVERTER HARNESS
4
SA5170001
1
PROGRAMMER PCB ASS
Y
5
SA5172001
1
SWITCH PCB ASS
Y
6
XD1115051
2
FFC: SML2CD-20X70
7
SA5167001
1
PROGRAMMER HARNESS
8
SA4574001
1
KEYBOARD
BAS-342G-940
56
60
62
Table of Contents
Table of Contents
5
A1. Machine Body
7
A2. Machine Body
11
Upper Shaft and Needle Bar Mechanism
13
C1. Feed Mechanism
15
C2. Feed Mechanism
17
C3. Feed Mechanism
19
D1. Work Clamp Lifter Mechanism
21
D2. Work Clamp Lifter Mechanism
23
Lower Shaft Mechanism
25
Lubrication
27
Threading Mechanism
31
Bobbin Winder Mechanism
33
Thread Trimmer Mechanism
35
Thread Wiper Mechanism
39
Tension Release Mechanism
41
M1. Control Box Mechanism
43
M2. Control Box Mechanism (Power Supply Motor PCB)
45
Power Switch Mechanism
47
Air Pressure Mechanism
49
Power Supply Equipment Mechanism
51
Operation Panel Mechanism
53
Motor Mechanism
55
Foot Switch Pedal Mechanism
57
Power Table
59
Programmer
61
W1. Attachment Set (Option Parts)
63
W2. Attachment Set (Option Parts)
65
W3. Attachment Set (Option Parts)
67
W4. Attachment Set (Option Parts)
69
W5. Attachment Set (Option Parts)
71
Accessories
73
Wa. Warning Labels
75
Ap. Parts List Sorted by Application
76
Ga. Gauge Parts List
77
Index
79
