C2. / Feed mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA8578001 1
BALL BEARING, 6901ZZNR
4 SA8582001 1
PULLEY FULCRUM SHAFT
5 012500536 2 SET SCREW SOCKET (FT) M5X5
6 SA8583001 1
PULLEY FULCRUM SHAFT COLLAR
7 SA8584001 1 X-GT BELT
8 S47270001 2
BOLT SOCKET (S/P WASHER) M6X30
9 SA8585001 1
DRIVE SHAFT X
10 048150142 2
RETAINING RING EXTERNAL C15
11 SA8586001 1
GEAR X
12 012060636 4 SET SCREW SOCKET (FT) M6X6
13 SA6674001 1
BALL BEARING 6002ZZNR
14 SA8587001 1
15 012060636 4 SET SCREW SOCKET (FT) M6X6
16 076202850 2
BALL BEARING RADIAL 6202ZZN
BALL BEARING, 6901ZZNR
20 SA8582001 2
PULLEY FULCRUM SHAFT
21 012500536 4 SET SCREW SOCKET (FT) M5X5
22 SA8583001 2
PULLEY FULCRUM SHAFT COLLAR
23 SA8593001 2 Y-GT BELT
24 SA8595001 1
26 012060636 4 SET SCREW SOCKET (FT) M6X6
27 SA8587001 2
28 012060636 8 SET SCREW SOCKET (FT) M6X6
29 SA6674001 2
BALL BEARING 6002ZZNR
30 076202850 2
BALL BEARING RADIAL 6202ZZN
BOLT SOCKET M5X12
32 SA8602001 1
33 062400816 3 SCREW PAN M4X8
34 S47270001 4
BOLT SOCKET (S/P WASHER) M6X30
35 SA8604001 1
MOTOR BRACKET X
36 SA8599001 1
BALL BEARING 6201ZZNR
37 SA8538001 1 PULSE MOTOR ASSY
BOLT SOCKET M5X16
39 SA8607001 1
MOTOR GEAR X
40 012060636 2 SET SCREW SOCKET (FT) M6X6
41 S47270001 4
BOLT SOCKET (S/P WASHER) M6X30
42 SA8598001 1
BALL BEARING 6201ZZNR
44 SA8542001 1 PULSE MOTOR ASSY
BOLT SOCKET M5X16
46 SA8601001 1
MOTOR GEAR Y
47 012060636 2 SET SCREW SOCKET (FT) M6X6
48 S47269001 4
BOLT SOCKET (S/P WASHER) M6X20
49 SA8694001 2 FAN BRACKE
BOLT SOCKET M4X8
BAS-342G-202
12
To Next Page
