D2. / Work clamp lifter mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA4741101 1
MOTOR BRACKET
2 SA4742001 1
WORK CLAMP MOTOR PLATE
3 018501036 2
BOLT SOCKET M5X10
4 SA4826501 1 PULSE MOTOR ASSY P
5 018401036 4
BOLT SOCKET M4X10
6 SA4743001 1
7 012060636 2 SET SCREW SOCKET (FT) M6X6
8 SA4744001 1
WORK CLAMP FULCRUM SHAFT
9 SA4647001 2
BALL BEARING 6900ZZNR
10 048100142 2
RETAINING RING EXTERNAL C10
11 062400616 1 SCREW PAN M4X6
12 025040236 1
WASHER PLAIN M 4
13 SA4745001 1
SET SCREW SOCKET (CN) M6X10
15 012060636 1 SET SCREW SOCKET (FT) M6X6
16 SA4747001 1
WORK CLAMP H-POSITION DOG
17 018400636 1
BOLT SOCKET M4X6
18 SA4748101 1
19 012060636 1 SET SCREW SOCKET (FT) M6X6
20 SA6210001 1
STEPPING W-CLAMP DRIVING LEVE
W-CLAMP LIFTER ROLLER SHAFT
22 070696800 1
BALL BEARING RADIAL 696ZZ
23 109763001 1
24 012500536 1 SET SCREW SOCKET (FT) M5X5
25 012060636 1 SET SCREW SOCKET (FT) M6X6
26 SA4757101 1 SET SCREW COLLA
27 012060636 2 SET SCREW SOCKET (FT) M6X6
28 018061236 2
BOLT SOCKET M6X12
29 SA4753001 1
WORK CLAMP SENSOR PLATE
30 062400616 2 SCREW PAN M4X6
BAS-342G-204
18
