2-2 BE-1204B-BC • BE-1206B-BC
Chapter 2 Preparation of Embroidery Machine
1. Names of Machine Components
W1401Q
The machine heads are numbered 1 to 6 (1 to 4 in four head models) from the right front.
Fluorescent lamp switch
Operation panel
Thread tension dial
Thread guide C
Thread guide B
Thread guide A
Thread tension base switch
Cotton
stand
Table
Stop switch
Leg
Main power switch
Control box
Power switch
Fluorescent lamp
switch
Flat / Cap hoop
select switch
Emergency
stop switch
STEP BACK /
FWD switch
Start switch
Rotary hook cover (Safety device)
