Brother DCP-1610W User Manual

94
A
Consumable items A
The drum unit and toner cartridge are two separate consumables. Make sure both are installed as
an assembly. For more information on how to replace the consumable items, see the instructions
included with the drum unit for replacing the drum unit or see the instructions printed on the box
of the toner cartridge for replacing the toner cartridge.
IMPORTANT
• Brother machines are designed to work with toner of a particular specification and will work to
a level of optimum performance when used with Brother Original toner cartridges. Brother
cannot guarantee this optimum performance if toner or toner cartridges of other specifications
are used. The machine may not detect toner or toner cartridges of other specifications correctly
but may instead detect such items as standard yield toner cartridges. Brother does not
therefore recommend the use of cartridges other than Brother Original cartridges with this
machine, or the refilling of empty cartridges with toner from other sources. If damage is caused
to the drum unit or other parts of this machine as a result of the use of toner or toner cartridges
other than Brother Original products due to the incompatibility or lack of suitability of those
products with this machine, any repairs required as a result may not be covered by the
warranty.
• For best performance, use a Brother Original drum and toner cartridge. Printing with a third
party drum unit or toner cartridge may reduce not only the print quality but also the quality and
life of the machine itself. Warranty coverage may not apply to problems caused by the use of
a third party drum or toner cartridge.
Troubleshooting and other
information
A
Toner cartridge Drum unit
Model Name:
(For Vietnam) TN-1010
(For India) TN-1020
(For Australia and other Oceania countries)
TN-1070
(For Indonesia) TN-1080
(For other Asian countries) TN-1000
Model Name:
(For Vietnam) DR-1010
(For India) DR-1020
(For Australia and other Oceania countries)
DR-1070
(For Indonesia) DR-1080
(For other Asian countries) DR-1000

Brother DCP-1610W Specifications

General

Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	20 cpm
Scan to	E-mail, File, Image
Scan drivers	ICA, TWAIN, WIA
Maximum scan area	A4 (210 x 297) mm
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 1200 DPI
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 1800 pages per month
Number of print cartridges	1
Page description languages	GDI
Built-in processor	Yes
Sound pressure level (printing)	52 dB
Total input capacity	150 sheets
Total output capacity	50 sheets
Custom media length	148 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	65 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SMTP-AUTH, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port 9100, IPP, FTP Server, SNMPv1/v2c, HTTP Server, TFTP Client/Server, SMTP Client, ICMP, Web Services
Supported network protocols (IPv6)	NDP, RA, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port 9100, IPP, FTP Server, SNMPv1/v2c, HTTP Server, TFTP Client/Server, SMTP Client, ICMPv6, Web Services
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1080 W
Power consumption (off)	0.28 W
Power consumption (ready)	50 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	390 W
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	Brother BRAdmin Light Network Management
Sustainability certificates	ENERGY STAR
Package depth	436 mm
Package width	481 mm
Package height	406 mm
Package weight	9000 g
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	340 mm
Width	385 mm
Height	255 mm
