Brother DCP-4020C - Carton Components; Control Panel

Carton components may differ from one country to another.
Save all packing materials and the carton.
Carton Components
Quick Setup Guide
CD-ROM
User’s Guide
Output Paper Support Paper Tray
Ink Cartridges
(Black, Cyan, Yellow, Magenta)
Power Cord
USB Cable
■
You must use the appropriate USB cable.
■
Use only a USB interface cable that is no longer than 2 meters.
Control Panel
1
. Photo Capture Centre and
On/Off keys
2
. Liquid Crystal Display (LCD)
4
. Numeric keys
3
. Navigation keys
5
. Scan and Copy keys
For the details of the control panel, see "DCP-4020C control panel overview" in Chapter 1 of the
User’s Guide.
1
3
4
1. Control Panel
2. Scanner Cover Release Lever
2
3. Scanner Cover
4. Document Cover
1 2 3 4 5
■
Getting Started
