Brother DCP-7030 Quick Setup Guide

Table of Contents
1
Getting Started
Safety Precautions ....................................................................................................................................... 2
To use the machine safely ...................................................................................................................... 2
Regulations ............................................................................................................................................. 4
Carton components...................................................................................................................................... 6
Control panel................................................................................................................................................ 7
STEP 1 – Setting Up the Machine
Installing the drum unit and toner cartridge assembly.................................................................................. 8
Loading paper in the paper tray ................................................................................................................... 9
Install the power cord ................................................................................................................................. 10
Selecting your language ............................................................................................................................ 10
Setting the LCD contrast ............................................................................................................................ 11
STEP 2 – Installing the Driver & Software
Windows
®
For USB Interface Cable Users
(For Windows
®
2000 Professional/XP/XP Professional x64 Edition/Windows Vista
®
) ............................. 14
For Wired Network Interface Users (DCP-7045N only)
(For Windows
®
2000 Professional/XP/XP Professional x64 Edition/Windows Vista
®
) ............................. 17
For Windows Server
®
2003, see the Network User’s Guide on the CD-ROM.
Macintosh
®
For USB Interface Cable Users................................................................................................................. 20
For Mac OS
®
X 10.2.4 or greater......................................................................................................... 20
For Wired Network Interface Users (DCP-7045N only) ............................................................................ 22
For Mac OS
®
X 10.2.4 or greater......................................................................................................... 22
For Network Users
BRAdmin Light utility (For Windows
®
users).............................................................................................. 25
Installing the BRAdmin Light configuration utility .................................................................................. 25
Setting your IP address, Subnet Mask and Gateway using BRAdmin Light ........................................ 25
BRAdmin Light utility (For Mac OS
®
X users)............................................................................................ 26
Setting your IP address, Subnet Mask and Gateway using BRAdmin Light ........................................ 26
Web Based Management (web browser)................................................................................................... 27
Restoring the network settings to factory default ....................................................................................... 27
Print the Network Configuration List........................................................................................................... 27
Consumables and Options
Consumables ............................................................................................................................................. 28

Brother DCP-7030 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 1600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Scan to	E-mail
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	9600 x 9600 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	22 cpm
Total input capacity	250 sheets
Total output capacity	100 sheets
Internal memory	16 MB
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	51 dB
Display	LCD
Product color	White
Market positioning	Home & office
Paper tray media types	Bond paper, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 257 mm
All-in-one functions	Copy, Scan
Color all-in-one functions	No
Power consumption (standby)	80 W
Power consumption (PowerSave)	10 W
Power consumption (average operating)	460 W
Package depth	510 mm
Package width	550 mm
Package height	454 mm
Package weight	13400 g
Maximum duty cycle	- pages per month
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	396 mm
Width	428 mm
Height	257 mm
