Printing
26
2
User Authentication (For MFC-7860DW) 2
If you are restricted from PC Print by the Secure Function Lock 2.0 feature, you need to set your ID and PIN
in the User Authentication Settings dialog. Click Settings of User Authentication and select Use ID
Name/PIN.
If you want to enter your ID and PIN each time you print, select Enter ID Name/PIN for each print job.
If you want to remember the ID Name/PIN, enter your ID and PIN.
If your PC login name is registered to Secure Function Lock 2.0, you can select Use PC Login Name instead
of entering your ID and PIN.
For more information about Secure Function Lock 2.0, see the Network User's Guide.
Note
When you use the machine through a network you can see the information of your ID such as the status
of restricted features and the number of remaining pages you are allowed to print by clicking the Check
Print Status. The Authentication result dialog will appear.
When you use the machine through a network, you can make the Authentication result dialog appear
each time you print by checking the Show print status before printing.
Other Print Options 2
You can set the following in Printer Function:
Macro (For DCP-7070DW and MFC-7860DW)
Density Adjustment
Improve Print Output
Skip Blank Page
Macro (For DCP-7070DW and MFC-7860DW) 2
You can save a page of a document as a macro to machine memory. You can also execute the saved macro
(you can use the saved macro as an overlay on any documents). This will save time and increase printing
speed for often used information such as forms, company logos, letterhead formats or invoices.
Note
If the power switch is Off, all data will be deleted.
Density Adjustment 2
Increase or decrease the print density.
Note
The Density Adjustment is not available when you set the Resolution to HQ 1200.
