Brother DCP-L5650DN Service Manual

2-53
Confidential
 Error code 7301
When printing from the paper tray 1, the T1 paper feed sensor does not detect paper pass
within the specified time while the T1 paper empty sensor detects some paper set.
 Error code 7302
When printing from the paper tray 1, the registration front sensor does not detect paper pass
within the specified time after the T1 paper feed sensor detected paper pass.
<User Check>
• Remove the jammed paper.
• Add the paper properly using the paper tray 1 paper guide.
Step Cause Remedy
1
Foreign object in the front of the
machine
Remove the foreign object.
2
T1 paper pick up roller holder
attachment failure
Reattach the T1 paper pick up roller holder.
3
T1 paper feed actuator
attachment failure
Reattach the T1 paper feed actuator.
4
Connection failure of the T1
pickup clutch harness
Reattach the T1 pickup clutch harness.
5
Connection failure of the T1
paper feed sensor harness
Reconnect the T1 paper feed sensor harness.
6
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
7 PF kit 1 failure Replace the PF kit 1.
8 T1 pickup clutch failure Replace the T1 pickup clutch.
9
T1 paper feed sensor PCB failure Replace the T1 paper feed sensor PCB ASSY.
10
T1 paper empty sensor PCB failure Replace the T1 paper empty sensor PCB ASSY.
11
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
12
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
13 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Remove the jammed paper.
• Add the paper properly using the paper tray 1 paper guide.
Step Cause Remedy
1
Foreign object in the front of the
machine
Remove the foreign object.
2
Registration front actuator
attachment failure
Reattach the registration front actuator.
3
Connection failure of the registration
front/rear sensor harness
Reconnect the registration front/rear sensor
harness.
4
Registration front/rear sensor
PCB failure
Replace the registration front/rear sensor PCB
ASSY.
5
high-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
6
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
7 Main PCB failure Replace the main PCB ASSY.
