2-54
Confidential
Error code 7401
When printing from the paper tray 2, the T2(LT or TT) paper feed sensor does not detect
paper pass within the specified time while the T2(LT or TT) paper empty sensor detects some
paper set.
<User Check>
Remove the jammed paper.
Add the paper properly using the paper tray 2 paper guide.
Step Cause Remedy
1
Foreign object in the front of the
machine
Remove the foreign object.
2
Malfunction of the LT control
PCB or TT control PCB
Install the latest main firmware.
3
T2(LT or TT) paper pick up roller
holder attachment failure
Reattach the T2(LT or TT) paper pick up roller
holder.
4
T2(LT or TT) paper feed
actuator attachment failure
Reattach the T2(LT or TT) paper feed actuator.
5
Connection failure of the T2(LT
or TT) pickup clutch harness
Reconnect the T2(LT or TT) pickup clutch
harness.
6
Connection failure of the T2(LT
or TT) paper feed sensor
harness
Reconnect the T2(LT or TT) paper feed sensor
harness.
7 PF kit 2 failure Replace the PF kit 2.
8
T2(LT or TT) pickup clutch
failure
Replace the T2(LT or TT) pickup clutch.
9
T2(LT or TT) paper feed sensor
PCB failure
Replace the T2(LT or TT) paper feed sensor
PCB ASSY.
10
T2(LT or TT) paper empty
sensor PCB failure
Replace the T2(LT or TT) paper empty sensor
PCB ASSY.
11 T2LT control PCB failure Replace the T2LT control PCB ASSY.
12 TT control PCB failure Replace the TT control PCB ASSY.
13
TT low-voltage power supply
PCB failure
Replace the TT low-voltage power supply PCB
ASSY.
14 Main PCB failure Replace the main PCB ASSY.
