Chapter 4
28
Out of Paper Reception 4
As soon as the paper tray becomes empty
during fax reception, the LCD shows No
Paper. Put some paper in the paper tray.
(See Loading paper and print media in
Chapter 2 of the Basic User's Guide.)
The machine will carry on receiving the fax,
with the remaining pages being stored in
memory, if enough memory is available.
Incoming faxes will continue to be stored in
the memory until the memory becomes full or
paper is loaded in the paper tray. When the
memory is full the machine will stop
automatically answering calls. To print the
faxes, put fresh paper in the tray and press
Start.
(For MFC-7360N and MFC-7460DN)
For details on how to set the Memory Receive
manually, see Receiving faxes into memory
(MFC-7360N and MFC-7460DN)
on page 27.
Polling overview 4
Polling lets you set up your machine so other
people can receive faxes from you, but they
pay for the call. It also lets you call somebody
else’s fax machine and receive a fax from it,
so you pay for the call. The polling feature
needs to be set up on both machines for this
to work. Not all fax machines support polling.
Polling receive 4
Polling receive lets you call another fax
machine to receive a fax.
a Make sure you are in Fax mode .
b For MFC-7360N and MFC-7460DN,
press Menu, 2, 1, 8.
For MFC-7860DW, press Menu, 2, 1, 7.
c Press a or b to choose Standard.
Press OK.
d Enter the fax number you are polling.
Press Start.
Secure polling 4
Secure polling lets you restrict who can get
the documents you set up to be polled.
Secure polling only works with Brother fax
machines. If you want to get a fax from a
secured Brother machine you have to enter
the secure code.
a Make sure you are in Fax mode .
b For MFC-7360N and MFC-7460DN,
press Menu, 2, 1, 8.
For MFC-7860DW, press Menu, 2, 1, 7.
c Press a or b to choose Secure.
Press OK.
d Enter a four-digit secure code.
Press OK.
This is the security code of the fax
machine you are polling.

Table of Contents

Other manuals for Brother HL-2250DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-2250DN and is the answer not in the manual?

Brother HL-2250DN Specifications

General IconGeneral
ColorNo
N-up printing2, 4, 6, 25
Print technologyLaser
Maximum resolution2400 x 600 DPI
Economical printingYes
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)26 ppm
Duplex print speed (black, normal quality, A4/US Letter)5 ppm
Maximum internal memory- MB
Sound power level (standby)31 dB
Sound pressure level (printing)53 dB
Total input capacity250 sheets
Total output capacity100 sheets
Total number of input trays1
Maximum duty cycle- pages per month
Page description languagesPCL 6
Custom media width76.2 - 216 mm
Maximum print size216 x 406 mm
Custom media length116 - 406.4 mm
Paper tray media typesBond paper, Plain paper, Recycled paper
Paper tray media weight60 - 105 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Sustainability certificatesENERGY STAR
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)65 W
Power consumption (printing)495 W
Power consumption (PowerSave)0.9 W
Package weight8300 g
Operating temperature (T-T)10 - 32.5 °C
Operating relative humidity (H-H)20 - 80 %
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)368 x 360 x 183 mm
