2. IF YOU REPLACE THE LOW-VOLTAGE

POWER SUPPLY PCB ASSY

 What to do after replacement

• Reset Irregular Power Supply Detection Counter of the Low-voltage Power Supply PCB

 What you need to prepare

None

2.1

Reset Irregular Power Supply Detection Counter of the

Low-voltage Power Supply PCB

LED models

Refer to “1.4.14 Reset irregular power supply detection counter of low-voltage power supply

PCB” in Chapter 5 to reset the irregular power supply detection counter.

LCD models

Refer to “1.3.21 Reset irregular power supply detection counter of low-voltage power supply

PCB (Function code 88)” in Chapter 5 to reset the irregular power supply detection counter.
