Brother LX2500 User Manual

Appliqué, Patchwork and Quilt Stitching 97
3
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Satin stitching
A decorative stitch can be sewn by changing the
stitch width of a satin stitch. If the sewing machine is
set so that the stitch width can be adjusted using the
sewing speed controller, the stitch width can quickly
and easily be adjusted. In this case, the sewing speed
is adjusted with the foot controller.
a
Connect the foot controller.
• For details, refer to "Starting to sew" (page
47).
b
Attach zigzag foot "J".
• For details, refer to "Replacing the presser
foot" (page 38).
c
Turn on the sewing machine, and then press
(Settings key) in the operation panel.
X The settings screen appears.
d
Press (Next page key) until "WIDTH
CONTROL" is on LCD screen, and the press
ON for stitch width control setting.
X The machine is now set so that the stitch
width can be controlled with the sewing
speed controller.
e
Press (Back key).
X The initial screen appears again.
f
Select stitch
60
.
• For details, refer to "Selecting stitching" (page
45).
g
While sewing, slide the sewing speed
controller to adjust the stitch width.
Slide the controller to the left to make the width
narrower. Slide the controller to the right to
make the width wider.
• Adjust the sewing speed with the foot
controller.
h
When you are finished sewing, set the stitch
width control setting back to OFF.
Memo
z Although the stitching result differs
depending on the type of fabric being sewn
and the thickness of the thread being used,
for best results, adjust the stitch length to
between 0.3 and 0.5 mm (1/64 and 1/32
inch).
J
WiderNarrower

Brother LX2500 Specifications

General

Maximum Stitch Width	5 mm
Maximum Stitch Length	4 mm
Free Arm	Yes
Type	Mechanical
Bobbin Type	Top Drop-in
Stitch Functions	Decorative
Dimensions	37.5 x 17.5 x 29 cm
