Brother LX2500 User Manual

1
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — Introduction
Introduction
Thank you for purchasing this sewing machine. Before using this sewing machine, carefully read the
"Important Safety Instructions" (page 5), and then study this manual for the correct operation of the various
functions. In addition, after you have finished reading this manual, store it where it can quickly be
accessed for future reference.
Sewing Machine Features
a Thread cassette
Easily thread the upper thread by loading a spool of thread into the thread cassette. Then, simply insert the thread cassette
into the compartment to thread the needle. (page 22)
b Simple bobbin-winding
The bobbin can quickly and easily be wound with thread. (page 16)
c Built-in stitches
You can select from the built-in stitches available, including utility stitches and decorative stitches. (page 64)
d One-touch lower threading
You can start sewing without pulling up the bobbin thread. (page 19)
e Automatic thread cutting
The thread can be cut automatically after sewing. (page 57)
f Embroidery
You can embroider built-in embroidery patterns, characters, framed decorations, and designs from optional embroidery
cards. (page 111)
6
4
3
2
1
5

Brother LX2500 Specifications

General

Maximum Stitch Width	5 mm
Maximum Stitch Length	4 mm
Free Arm	Yes
Type	Mechanical
Bobbin Type	Top Drop-in
Stitch Functions	Decorative
Dimensions	37.5 x 17.5 x 29 cm
