No. Name Description
(1) Document support This supports documents (original) loaded.
(2) Top cover Load documents (original) here.
(3) Control panel
Use the keys to operate the machine. The liquid crystal display
(LCD) shows the machine operation status.
(4) Document tray Scanned documents come out here.
(5) Paper tray Load paper here. Paper will be fed into the machine, sheet by sheet.
(6) Telephone line jack Plug in the modular plug on the telephone line here.
(7) External telephone line jack Plug in the modular plug on the external telephone line here.
(8)
LAN cable connector
(MFC3340CN/FAX1940CN)
Connect the LAN cable here.
(9) USB interface connector Connect the USB cable here.
(10) Jam clear cover Open to remove paper jammed inside the machine.
