Brother MFC-5890CN User Manual

156
No Paper Fed The machine is out of paper or
paper is not properly loaded in the
paper tray.
Do one of the following:
 Refill the paper in the paper tray, and
then press Black Start or Color Start.
 Remove the paper and load it again
and then press Black Start or
Color Start. (See Loading paper and
other print media on page 9.)
The paper is jammed in the
machine.
Remove the jammed paper by following
the steps in Printer jam or paper jam
(MFC-5890CN and MFC-5895CW)
on page 162 or Printer jam or paper jam
(MFC-6490CW only) on page 164.
The jam clear cover
(MFC-5890CN and
MFC-5895CW) or the outer back
cover or inner back cover
(MFC-6490CW) may not be
closed properly.
(MFC-5890CN and MFC-5895CW)
Open the jam clear cover and then close it.
Make sure the jam clear cover is closed
properly.
(MFC-6490CW)
Open the outer back cover and inner back
cover. Then close the inner back cover and
outer back cover. Make sure they are
closed properly.
No Response/Busy The number you dialed does not
answer or is busy.
Verify the number and try again.
Not Registered You tried to access a One Touch
or Speed Dial number that is not
programmed.
Set up the One Touch or Speed Dial
number. (See Storing Speed Dial numbers
on page 83.)
Out of Memory The machine's memory is full. Fax sending or copy operation in
progress
Do one of the following:
 Press Stop/Exit and wait until the other
operations in progress finish and then
try again.
 Clear the data in the memory. To gain
extra memory, you can turn off Memory
Receive. (See Receiving faxes into
memory when the paper tray is empty
on page 55.)
 Print the faxes that are in the memory.
(See Printing a fax from the memory
on page 55.)
The memory card or USB flash
memory drive you are using does
not have enough free space to
scan the document.
Delete unused files from your memory card
or USB Flash memory drive to make some
free space and then try again.
Error Message Cause Action

Brother MFC-5890CN Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	28 ppm
Scan to	E-mail, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Scan speed (black)	3.44 ppm
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	80
Total input capacity	150 sheets
Total output capacity	50 sheets
Processor family	RISC
Compatible memory cards	CF, Memory Stick (MS), miniSD, MS PRO, MS Pro, SD, SDHC, xD
Sound pressure level (printing)	50 dB
Display	LCD
Display diagonal	3.3 \
Market positioning	Home & office
Maximum print size	297 x 432 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	485 x 408 x 242 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
AC input frequency	50 - 60 Hz
Power consumption (standby)	6 W
Power consumption (PowerSave)	4.5 W
Power consumption (average operating)	27 W
Maximum duty cycle	- pages per month
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
