Brother MFC-790CW Quick Setup Guide

28
For Wireless Network Users
15
Confirm your network environment (Infrastructure Mode)
The following instructions will offer two methods for installing your Brother machine in a wireless network
environment. Both methods are for infrastructure mode, using a wireless router or access point that uses DHCP
to assign IP addresses. Choose a configuration method and proceed to the page indicated.
a If your wireless router/access point does not support SecureEasySetup™, Wi-Fi Protected Setup™
or AOSS™, write down the wireless network settings of your access point or wireless router in the
area below.
Important
If you do not know this information (Network Name, WEP key or WPA2-PSK (Pre-Shared Key)),
you cannot continue the wireless setup. You should see the documentation provided with your
access point or wireless router, consult the router manufacturer, or your system administrator.
SSID (Service Set ID or Network name)
Authentication (Open System or Shared Key)/Encryption Type (None or WEP)
WEP Key (if needed)
1
WPA/WPA2-PSK Encryption type (TKIP or AES) (if needed)
2
WPA/WPA2-PSK (Pre-Shared Key) (if needed)
2
1
The WEP key is for 64-bit encrypted networks or 128-bit encrypted networks and can contain both numbers and letters. If you do
not know this information you should see the documentation provided with your access point or wireless router. This key is a 64-
bit or 128-bit value that must be entered in an ASCII or HEXADECIMAL format.
For example:
64-bit ASCII: Uses 5 text characters e.g. “Hello” (this is case sensitive)
64-bit Hexadecimal: Uses 10 digits of hexadecimal data e.g. “71f2234aba”
128-bit ASCII: Uses 13 text characters e.g.
“Wirelesscomms” (this is case sensitive)
128-bit Hexadecimal:
Uses 26 digits of hexadecimal data e.g.
“71f2234ab56cd709e5412aa3ba”
2
WPA/WPA2-PSK is a Wi-Fi
®
Protected Access Pre-Shared Key, which lets the Brother wireless machine associate with access
points using TKIP or AES encryption (WPA-Personal). WPA/WPA2-PSK (TKIP or AES) uses a Pre-Shared Key (PSK) that is 8 or
more characters in length, up to a maximum of 63 characters.
See the Network User’s Guide for more details.
Now go to
page 29
b If your wireless router/access point supports automatic wireless (one-push) setup
(SecureEasySetup™, Wi-Fi Protected Setup™ or AOSS™)
Now go to
page 31

Brother MFC-790CW Specifications

General

Print technology	Inkjet
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Grayscale levels	256
Maximum scan resolution	19200 x 19200 DPI
PC free copying	Yes
Maximum copy resolution	1200 x 1200 DPI
Copy speed (black, normal quality, A4)	22 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	15 sheets
Display	LCD
Display diagonal	4.2 \
Market positioning	Home & office
Compatible memory cards	CF, MS Pro, SD, SDHC, xD
Envelopes sizes	C5, DL
Paper tray media types	Glossy paper, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size)
JIS B-series sizes (B0...B9)	B5
Ethernet LAN	No
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	460 x 375 x 180 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	fax, print, scan
