Brother MFC-8520DN Service Manual

5-20
Confidential
 Detailed description
Auto Skip Setting to skip at back end/tip of
paper
On/Off On
Left Margin Left margin setting 0 to 145 (columns) 0 (column)
Right Margin Right margin setting 10 to 155 (columns) 80 (columns)
Top Margin Top margin setting 0 to 2.00 (inches) 0.5 (inches)
Bottom Margin Bottom margin setting 0 to 2.00 (inches) 0.5 (inches)
Lines Setting of text lines per page 5 to 128 (lines) 60 (lines)
Error Print Error Print setting in the event of
PostScript error
On/Off On
LCD Detail description
Manual Feed Valid for printing from the computer, or for printing NetWorkConfig,
TestPrint, Fontlist, or Configuration from the panel. When the tray is selected
on the computer, the setting on the computer supersedes the setting on the
LCD.
Resolution Valid for printing from the computer. When the resolution is set on the
computer, the setting on the computer supersedes the setting on the LCD.
Toner Save Valid for all types of printing except copy, and the Function Menu setting can
also be changed. When Toner Save is set on the computer, the setting on
the computer supersedes the setting on the LCD.
Density Valid for printing from the computer, or for printing NetWorkConfig,
TestPrint, FontList, or Configuration from the panel. Linked with the Toner
Save setting, and the density is determined based on both settings. When
the density is set on the computer, the setting on the computer supersedes
the setting on the LCD.
JB-Can Time Sets the time until the host timeout is triggered when a job is cancelled. The
setting unit is on the second time scale.
Sleep Time Sets the time until the sleep mode is entered. The Function Menu setting can
also be changed.
Page Protection Sets the page memory to be secured for data processing before printing in
the computer. As this is a setting in the PCL-Core, this does not affect the
memory management of the machine.
Emulation Changes the print language. The Function Menu setting becomes valid.
When the data contains the ENTER LANGUAGE setting, this setting
supersedes the setting on the LCD.
Auto I/F Time Changes the interface open time. This setting becomes valid when PC-Print
is instructed, and becomes invalid when PC-Scan or Remote-SetUp is
instructed.
Media Type Valid for printing from the computer. When the type of paper is set on the
computer, the setting on the computer supersedes the setting on the LCD.
The default varies depending on the country setting. "Thin" is the default for
China and "Plain" is the default for other countries.
Paper Size Changes the image development area. Sets the drawing size for PC-Print,
instead of the setting for Paper Size in the menu. When the paper size is set
on the computer, the setting on the computer supersedes the setting on the
LCD. The default varies depending on the country setting. "Letter" is the
default for the US and Canada and "A4" is the default for other countries.
Copies Valid for printing from the computer. When the number of copies is set on
the computer, the setting on the computer supersedes the setting on the
LCD.
LCD Description Set value Default

Brother MFC-8520DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
PictBridge	No
Scan speed	2.68 sec/page
Dimensions (WxDxH)	405 x 415 x 423 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Printing colors	Black
Maximum duty cycle	- pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	36 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	ICA, ISIS, TWAIN
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	300
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	LCD
Market positioning	Home & office
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	Ethernet, USB 2.0
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, EAP-TTLS, MD5, PEAP
Processor family	Star Sapphire
Maximum internal memory	384 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	1.2 W
Power consumption (standby)	8.1 W
Power consumption (PowerSave)	336 W
Power consumption (average operating)	651 W
Package weight	20.100 g
Sustainability certificates	ENERGY STAR
