Brother MFC-8860DN Servise Manual

8-12 Confidential
Firmware Switches (WSW01 through WSW53) Continued
WSW No. Function
WSW38 V.34 transmission settings
WSW39 V.34 transmission speed
WSW40 V.34 modem settings
WSW41 ON-duration of the scanning light source
WSW42 Internet mail settings
WSW43 Function setting 21
WSW44 Speeding up scanning-1
WSW45 Speeding up scanning-2
WSW46 Monitor of power ON/OFF state and parallel port kept at high
WSW47 Switching between high- and full-speed USB
WSW48 USB setup latency
WSW49 End-of-copying beep and print in black
WSW50 SDAA settings
WSW51 Function setting 16
WSW52 Not used
WSW53 Function setting 18
Operating Procedure
(1) Press the [1] and [0] keys in this order in the initial stage of the maintenance mode.
The machine displays the “WSW0
0” on the LCD and becomes ready to accept a
firmware switch number.
(2) Enter the desired number from the firmware switch numbers (01 through 53).
The following appears on the LCD:
Selector 1 Selector 8
↓ ↓
WSWXX = 0 0 0 0 0 0 0 0
(3) Enter a value to be set (0 or 1) using the [0] and [1] keys.
(4) Press the [OK] key. This operation saves the newly entered selector values onto the
EEPROM and readies the machine for accepting a firmware switch number.
(5) Repeat steps (2) through (5) until the modification for the desired firmware switches is
completed.
(6) Press the [Stop/Exit] key to return the machine to the initial stage of the maintenance
mode.
NOTE:
- To cancel this operation and return the machine to the initial stage of the maintenance
mode during the above procedure, press the [Stop/Exit] key.
- If there is a pause of more than one minute after a single-digit number is entered for
double-digit firmware switch numbers, the machine will automatically return to the
initial stage of the maintenance mode.
Details of Firmware Switches
- The details of the firmware switches are described in Appendix 4 in which the user-
accessible selectors of the firmware switches are shaded.
- Machine w/o fax support some selectors of firmware switches. Those selector numbers
are circled.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
