9.1.1.2 Error codes shown in the "MACHINE ERROR X
X" message
Error Code
(Hex)
Symptom Probable Cause Solution
56 The fuser cover is opened. The fuser cover is
opened.
Close the fuser cover.
57 Duplex jam - Paper is remained.
- Main PCB defective
- Duplex reverse gear
damaged
- Duplex solenoid
defective
- Remove the jammed
paper.
- Replace the main PCB.
- Replace the duplex
reverse gear.
- Replace the duplex
solenoid.
58, 59 Not used.
5A High-voltage power supply
PCB malfunction
High-voltage power
supply PCB malfunction
Replace the High-voltage
power supply PCB.
New toner actuator
lever broken
Replace the new toner
actuator.
5B New toner sensor lever error
(New toner sensor stays on)
New toner sensor
defective
Replace the new toner
sensor.
5C Optional lower tray
(LT-5300) error
Two or more optional
lower trays are installed.
Install one optional lower
tray.
5D Duplex printing cannot be
implemented.
Close the rear cover of the
machine and put the
duplex tray back in.
5E, 5F Not used.
60 Recording paper is stacked
too much in the eject section.
Stacker sensor defective Replace the stacker
sensor.
61-67 Not used.
68 Side thermistor high
temperature error
Side thermistor short
circuit
Replace the side
thermistor.
69 Side thermistor low
temperature error
Side thermistor break Replace the side
thermistor.
Thermistor defective Replace the thermistor. 6A Heater warming-up timeout
error. (Heater does not reach
60 ˚С
within 12 second.)
Halogen lamp defective Replace the halogen lamp.
Thermistor defective Replace the thermistor. 6B Heater warming-up timeout
error. (Heater does not reach
100 ˚С
within 9 second.)
Halogen lamp defective Replace the halogen lamp.
Thermistor defective Replace the thermistor. 6C Heater temperature exceeds
the maximum high
temperature. (270˚С or more
is detected for 1sec.)
Power supply PCB
defective
Replace the power supply
PCB.
6D Not used.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
