Brother MFC-8860DN Servise Manual

App. 4-24 Confidential
WSW20
(Overseas communications mode setting)
Selector
No.
Function
Setting and Specifications
1 EP* tone prefix 0: OFF 1: ON
2
Overseas communications
mode (Reception)
0: 2100 Hz 1: 1100 Hz
3
Overseas communications
mode (Transmission)
0: OFF 1: Ignores DIS once.
4
5
Min. time length from
reception of CFR to start of
transmission of video signals
No. 4 5
0 0 : 100 ms
0 1 : 200 ms
1 0 : 300 ms
1 1 : 400 ms
6
7
At CNG detection, elimination
of chattering noise
No. 6 7
0 0 : Yes, at both ON/OFF timings
0 1 : Yes, at OFF timing
1 X : No
8 Limitation on CNG detection 0: OFF 1: ON
* EP: Echo protection
NOTE: Selectors 6 and 7 are applicable to models equipped with SDAA circuits.
- Selector 1: EP tone prefix
Setting this selector to "1" makes the machine transmit a 1700 Hz echo protection (EP) tone
immediately preceding training in V.29 modulation system to prevent omission of training signals.
Prefixing an EP tone is useful when the machine fails to transmit at the V.29 modem speed and
always has to fall back to 4800 bps transmission.
The setting made by this selector takes effect only when the Overseas Mode is set to ON.
- Selectors 2 and 3: Overseas communications mode
These selectors should be used if the machine malfunctions in overseas communications.
According to the communications error state, select the signal specifications.
Setting selector 2 to "1" allows the machine to use 1100 Hz CED signal instead of 2100 Hz in
receiving operation. This prevents malfunctions resulting from echoes, since the 1100 Hz signal
does not disable the echo suppressor (ES) while the 2100 Hz signal does.
Setting selector 3 to "1" allows the machine to ignore a DIS signal sent from the called station
once in sending operation. This operation suppresses echoes since the first DIS signal
immediately follows a 2100 Hz CED (which disables the ES) so that it is likely to be affected by
echoes in the disabled ES state. However, such a disabled ES state will be removed soon so that
the second and the following DIS signals are not susceptible to data distortion due to echoes. Note
that some models when called may cause error by receiving a self-outputted DIS.
The setting made by selector 3 takes effect only when the Overseas Communications Mode is set
to ON. (The setting made by selector 2 is always effective.)

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
