Brother MFC-8860DN Servise Manual

App. 4-30 Confidential
WSW26
(Function setting 4)
Selector
No.
Function
Setting and Specifications
1
2
Not used.
3
Dialing during document
reading into the temporary
memory in in-memory message
transmission
0: Disable 1: Enable
4
5
No. of CNG cycles to be
detected
(when the line is connected via
the external telephone except in
the external TAD mode or via
the built-in telephone)
No. 4 5
0 0 : 0.5 (A)
0 1 : 1 (B)
1 0 : 1.5 (C)
1 1 : 2 (D)
6
7
No. of CNG cycles to be
detected
(when the line is connected via
the external telephone in the
external TAD mode, via the
built-in telephone in the TAD
mode, or via the machine in the
automatic reception of the F/T
mode)
No. 6 7
0 0 : 0.5 (A)
0 1 : 1 (B)
1 0 : 1.5 (C)
1 1 : 2 (D)
8 Not used.
- Selector 3: Dialing during document reading into the temporary memory in in-memory message
transmission
If this selector is set to "0," the machine waits for document reading into the memory to complete
and then starts dialing. This enables the machine to list the total number of pages in the header of
the facsimile message.
- Selectors 4 and 5: No. of CNG cycles to be detected (when the line is connected via the external
telephone except in the external TAD mode or via the built-in telephone)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of cycles
specified by these selectors when the line is connected via the external telephone except in the
external TAD mode or via the built-in telephone.
- Selectors 6 and 7: No. of CNG cycles to be detected (when the line is connected via the external
telephone in the external TAD mode, via the built-in telephone in the TAD mode, or
via the machine in the automatic reception of the F/T mode)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of cycles
specified by these selectors when the line is connected via the external telephone in the external
TAD mode, via the built-in telephone in the TAD mode, or via the machine in the automatic
reception of the F/T mode.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
