Carton components may differ from one country to another.
Save all packing materials and the carton.
Carton Components
Quick Setup Guide
CD-ROM
User’s Guide
Drum Unit Assembly
(including Toner Cartridge)
AC Power Cord Telephone Line Cord
■ To ensure safe operation the supplied plug must be inserted only into a standard power outlet that is
properly grounded through the standard electrical wiring. None grounded equipment may cause an
electrical shock hazard, and may cause excessive electrical noise radiation.
■ The interface cable is not a standard accessory. Please purchase the appropriate interface cable for
the interface you intend to use (Parallel, USB or Network).
■ Do NOT connect the interface cable at this time. Connecting the interface cable is done during the
software installation process.
■ USB interface cable
Please make sure you use a USB 2.0 interface cable that is no longer than 2.0 metres.
When you use a USB cable, make sure you connect it to the USB port of your computer and not to a
USB port on a keyboard or non-powered USB hub.
■ Parallel interface cable
Please make sure you use a Parallel interface cable that is no longer than 2.0 metres.
Use a shielded interface cable that is IEEE 1284-compliant.
■ Network cable
Use a straight-throgh Category 5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast
Ethernet Network.
1. Automatic Document Feeder (ADF)
2. Control Panel
3. Face-down Output Tray
Support Flap (Support Flap)
4. Front cover
5. Paper Tray
6. Power Switch
7. Document Cover
8. ADF Document Output Support Flap
1
6
2
3
4
5
8
7
