5
3
Install the drum unit and
toner cartridge
assemblies
a Unpack the four drum unit and toner cartridge
assemblies and gently shake each of them
from side to side several times to distribute the
toner evenly inside the assembly.
b Remove the protective cover by pulling on the
tab as shown in the illustration.
c Slide all four of the drum unit and toner
cartridge assemblies into the machine as
shown in the illustration. Make sure that you
match the toner cartridge color to the same
color label on the machine.
d Close the top cover of the machine.
Note
Do not touch the surface of the packing film. It
may contain toner powder which can stain your
skin and clothing.
IMPORTANT
To avoid print quality
problems, DO NOT touch the
surface of the drum unit.
C - Cyan Y - Yellow
M - Magenta K - Black
C
M
K
To Next Page
