16
Macintosh
USB
For USB interface users
(Mac OS X 10.4.11, 10.5.x, 10.6.x)
17
Before you install
Make sure your machine is connected to the power
and your Macintosh is ON. You must be logged on
with Administrator rights.
18
Connect the USB cable
a Using both hands, use the plastic tabs on both
sides of the machine to lift the scanner cover
until it locks securely into the open position.
b Connect the USB cable to the USB port
marked with a symbol. You will find the
USB port inside the machine as shown below.
c Carefully guide the USB cable into the cable
channel and out the back of the machine.
Connect the cable to your Macintosh.
For Mac OS X 10.4.0 to 10.4.10 users, upgrade to
Mac OS X 10.4.11 - 10.6.x.
• DO NOT connect the machine to a USB port
on a keyboard or a non-powered USB hub.
• Connect the machine directly to your
Macintosh.
Make sure that the cable does not restrict the
cover from closing, or an error may occur.
USB
To Next Page
