Brother MFC-J4420DW User Manual

34
g The Touchscreen displays a message
asking about the print quality.
Do one of the following:
 If all lines are clear and visible, press
No to finish the Print Quality check,
and then go to step k.
 If you can see missing short lines as
shown in the illustration, press Yes.
h The Touchscreen displays a message
asking you to check the print quality of
each color. Following the instructions on
the Touchscreen, press 1, 2, 3 or 4 to
select the example most similar to the
Print Quality Check Sheet for each
color.
i If you press number 2, 3, or 4, the
Touchscreen prompts you to start
cleaning.
Press Start.
j After the cleaning procedure is finished,
press Yes, and return to step e.
k Press .
If you clean the print head at least five times
and the print has not improved, try installing a
new Genuine Brother Brand replacement ink
cartridge for each problem color. Try cleaning
the print head up to five more times. If the
print has not improved, contact Brother
Customer Service. (See Brother numbers
on page i.)
IMPORTANT
DO NOT touch the print head. Touching
the print head may cause permanent
damage and may void the print head's
warranty.
NOTE
When a print head nozzle is clogged, the
printed sample looks like this.
Letter, A4 and Executive
Ledger, A3, Legal, A5, A6, envelopes,
Photo (4"  6")/(10  15 cm),
Photo L (3.5"  5")/(89  127 mm),
Photo 2L (5"  7")/(13  18 cm) and Index
Card (5"  8")/(127  203 mm)
After the print head nozzle is cleaned, the
horizontal lines are gone.
OK Poor

Brother MFC-J4420DW Specifications

General

Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 2400 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, SMB, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Image formats supported	BMP, EXIF, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Faxing	Color faxing
Modem speed	14.4 Kbit/s
Fax coding methods	MMR
Fax resolution (black)	203 x 203 DPI
Fax speed dialing (max numbers)	100
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Email protocols	POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, Picasa, Sky Drive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS / NetBIOS, DNS Resolver, mDNS, LLMNR, LPR / LPD, Custom Raw Port / Port 9100, IPP, FTP Client/Server, SNMPv1 / v2c, TFTP server, SMTP Client, ICMP, CIFS Client, SNTP Client, POP3, IMAP4, HTTP Server IPv6 NDP, RA, mDNS, LLMNR, DNS, LPR / LPD, Custom Raw Port / Port 9100, IPP, FTP Client / Server, SNMPv1 / v2, TFTP server, SMTP Client, POP3, CIFS Client, SNTP Client, IMAP4, ICMPv6, HTTP Server
Paper input type	Paper tray
Total input capacity	- sheets
Total output capacity	50 sheets
Maximum input capacity	150 sheets
Auto document feeder (ADF) input capacity	20 sheets
Envelopes sizes	10, DL, Monarch
Photo paper sizes	10x15, 13x18 cm
Custom media width	148 - 215.9 mm
Custom media length	148 - 355.6 mm
Duplex media weight	64 - 120 g/m²
Paper tray media types	Coated paper, Envelopes, Glossy paper, Photo paper, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	2L, Executive (184 x 267mm), Index card, L, Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B4, B5
Borderless printing media sizes	10x15, 2L, A3, A4, A6, Ledger, Letter
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	LCD
Control type	Touch
Product color	Black, Silver
Display diagonal	2.7 \
Market positioning	Home & office
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Fax compatibility	ITU-T G3
Sound pressure level (printing)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (standby)	5 W
Power consumption (PowerSave)	1.7 W
Power consumption (average operating)	23 W
Minimum storage drive space	50 MB
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	Brother BRAdmin Light\\r MFL-Pro Suite\\r PaperPort12 SE\\r Newsoft OCR (Mac)
Sustainability certificates	Blue Angel, ENERGY STAR
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	290 mm
Width	480 mm
Height	188 mm
