Brother MFC-J4535DW User Manual

Home > Security > Use IPsec > Configure an IPsec Template Using Web Based Management
Configure an IPsec Template Using Web Based Management
Related Models: MFC-J4535DW
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network > Security > IPsec Template.
Start from , if the navigation menu is not shown on the left side of the screen.
5. Click the Delete button to delete an IPsec Template. When an IPsec Template is in use, it cannot be
deleted.
6. Click IPsec Template that you want to create. The IPsec Template screen appears. The configuration fields
differ based on the Use Prefixed Template and Internet Key Exchange (IKE) you select.
7. In the Template Name field, type a name for the template (up to 16 characters).
8. If you selected Custom in the Use Prefixed Template drop-down list, select the Internet Key Exchange
(IKE) options, and then change the settings if needed.
9. Click Submit.
Related Information
• Use IPsec
• IKEv1 Settings for an IPsec Template
• IKEv2 Settings for an IPsec Template
• Manual Settings for an IPsec Template
Related Topics:
• Access Web Based Management
370

Brother MFC-J4535DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Duplex copying	-
Maximum copy resolution	1200 x 2400 DPI
Copy speed (black, normal quality, A4)	13 cpm
Copy speed (color, normal quality, A4)	10.5 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Scan speed (black)	17 ppm
Scan speed (color)	7 ppm
Maximum scan resolution	19200 x 19200 DPI
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	6000 pages per month
Number of print cartridges	4
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	3
Auto document feeder (ADF) input capacity	20 sheets
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Photo paper sizes (imperial)	3.5x5, 5x7, 5x8 \
Optional connectivity	Bluetooth, Ethernet, Near Field Communication (NFC), Wireless LAN
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSec, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	57 dB
Display	LCD
Control type	Touch
Product color	Gray
Market positioning	Home & office
Power consumption (max)	21 W
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (standby)	1.1 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, MacOS
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8
Package depth	312 mm
Package width	497 mm
Package height	464 mm
Package weight	12600 g
Cables included	AC

Weight and Dimensions

Depth	335 mm
Width	435 mm
Height	250 mm
