Brother MFC-J4535DW User Manual

Home > Security > Use Active Directory Authentication > Configure Active Directory Authentication Using
Web Based Management
Configure Active Directory Authentication Using Web Based
Management
Related Models: MFC-J4535DW
Active Directory authentication supports Kerberos authentication and NTLMv2 authentication. You must
configure the SNTP protocol (network time server) and DNS server configuration for authentication.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Administrator > User Restriction Function.
Start from
, if the navigation menu is not shown on the left side of the screen.
5. Select Active Directory Authentication.
6. Click Submit.
7. Select the Active Directory Authentication menu.
8. Configure the following settings:
Option Description
Storage Fax RX Data Select this option to store incoming fax data. You can print all incoming fax
data after you log on to the machine.
Remember User ID Select this option to save your User ID.
Active Directory Server
Address
Type the IP address or the server name (for example: ad.example.com) of
the Active Directory Server.
Active Directory Domain
Name
Type the Active Directory domain name.
Protocol & Authentication
Method
Select the protocol and authentication method.
Get User's Home Directory Select this option to obtain your home directory as the Scan to Network
destination. (available only for LDAP + kerberos authentication method)
LDAP Server Port Type the port number to connect the Active Directory server via LDAP
(available only for LDAP + kerberos authentication method).
LDAP Search Root Type the LDAP search root (available only for LDAP + kerberos
authentication method).
9. Click Submit.
386

Brother MFC-J4535DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Duplex copying	-
Maximum copy resolution	1200 x 2400 DPI
Copy speed (black, normal quality, A4)	13 cpm
Copy speed (color, normal quality, A4)	10.5 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Scan speed (black)	17 ppm
Scan speed (color)	7 ppm
Maximum scan resolution	19200 x 19200 DPI
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	6000 pages per month
Number of print cartridges	4
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	3
Auto document feeder (ADF) input capacity	20 sheets
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Photo paper sizes (imperial)	3.5x5, 5x7, 5x8 \
Optional connectivity	Bluetooth, Ethernet, Near Field Communication (NFC), Wireless LAN
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSec, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	57 dB
Display	LCD
Control type	Touch
Product color	Gray
Market positioning	Home & office
Power consumption (max)	21 W
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (standby)	1.1 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, MacOS
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8
Package depth	312 mm
Package width	497 mm
Package height	464 mm
Package weight	12600 g
Cables included	AC

Weight and Dimensions

Depth	335 mm
Width	435 mm
Height	250 mm
