Brother MFC-J4535DW User Manual

Home > Mobile/Web Connect > Brother Web Connect > Download and Save a Document to an External
Memory Device Using Brother Web Connect
Download and Save a Document to an External Memory Device Using
Brother Web Connect
Related Models: MFC-J4535DW
JPEG, PDF and Microsoft Office files can be downloaded from a service and saved directly on media connected
to the machine. Documents that other users have uploaded to their own accounts for sharing can also be
downloaded to your machine as long as you have viewing privileges for those documents.
• Make sure there is enough available space on your USB flash drive.
• To download other users’ documents, you must have access privileges to view the corresponding albums or
documents.
• Downloaded files are renamed based on the current date. For example, the first image saved on July 1,
would be named 07010001.jpg. Note that the region setting also determines the date format of the file name.
• Images are saved in the “BROTHER” folder, which can be found on the root level of the media.
IMPORTANT
DO NOT remove the USB flash drive while the message appears on the LCD. Otherwise, the USB flash
drive, or data stored on the USB flash drive could be damaged.
1. Insert a USB flash drive into your machine.
The LCD automatically changes.
2. Press [Web].
• If information regarding the Internet connection appears on the machine's LCD, read the information
and press [OK].
• Occasionally, updates or announcements about Brother Web Connect's features will appear on the
LCD. Read the information, and then press [OK].
3. Press a or b to display the service that hosts the document you want to download.
Press the service name.
4. Press a or b to display your account name, and then press it. If the PIN entry screen appears, enter the four-
digit PIN and press [OK].
5. Press a or b to display [Download: Media].
Press [Download: Media].
6. Follow the on-screen instructions to complete this operation.
• An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
• Some services do not require documents to be saved in albums. For documents not saved in albums,
select [See Unsorted Files] to select documents.
Related Information
• Brother Web Connect
431

Brother MFC-J4535DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Duplex copying	-
Maximum copy resolution	1200 x 2400 DPI
Copy speed (black, normal quality, A4)	13 cpm
Copy speed (color, normal quality, A4)	10.5 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Scan speed (black)	17 ppm
Scan speed (color)	7 ppm
Maximum scan resolution	19200 x 19200 DPI
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	6000 pages per month
Number of print cartridges	4
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	3
Auto document feeder (ADF) input capacity	20 sheets
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Photo paper sizes (imperial)	3.5x5, 5x7, 5x8 \
Optional connectivity	Bluetooth, Ethernet, Near Field Communication (NFC), Wireless LAN
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSec, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	57 dB
Display	LCD
Control type	Touch
Product color	Gray
Market positioning	Home & office
Power consumption (max)	21 W
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (standby)	1.1 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, MacOS
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8
Package depth	312 mm
Package width	497 mm
Package height	464 mm
Package weight	12600 g
Cables included	AC

Weight and Dimensions

Depth	335 mm
Width	435 mm
Height	250 mm
