Brother MFC-J5720DW Service Manual

5-65
Confidential
DARK PAGE High-level ink usage page count *5
PC:00001 PC print page count *6
COPY:00002 Total number of copies *6
FAX:00001 Total number of fax/report/list prints *6
MEDIA:00001 Memory card/PictBridge print page count
TEST PRINT:0000 Total number of test prints
A3P:00001 Total page count for paper sizes and types *7
DX P:0000000001 Total page count in duplex printing
DX JAM:00001 Jam count in duplex printing
DX PC:00001 PC print page count in duplex printing
DX CLCOPY:00001 Color copy page count in duplex printing
DX MNCOPY:00001 Monochrome copy page count in duplex printing
DX A3P:00001 Total printed page count for paper sizes and types in duplex printing *8
TRAY1 PAGE:00001 Total paper tray 1 printed page count
TRAY1 JAM:00001 Paper tray 1 jam count
TRAY2 PAGE:00001 Total paper tray 2 printed page count
TRAY2 JAM:00001 Paper tray 2 jam count
CD PAGE:00000 Label print count (Not used)
CD JAM:00000 Jam count in label printing (Not used)
BYPASS PAGE:00001 Total print count in printing via manual feed slot
BYPASS JAM:00001 Jam count in printing via manual feed slot
MP TRAY PAGE:00001 Total MP tray printed page count
MP TRAY JAM:00001 MP tray jam count
ROLLER CLEANING Roller cleaning count *9 (Not used)
PP REMOVE:001 Paper piece removal count (Not used)
PURGE:00001 Purge count *10
SEN PURGE:00001 Sensor purge count (Not used)
eIP_BK:001/001 Purge count for purge types Auto/Manual (black) *11
eIP_CL:001/001 Purge count for purge types Auto/Manual (color) *11
WIPE:00001 Wipe count
FLSBK:0000000001 Flushing count (black) *10
FLSCL:0000000001 Flushing count (color) *10
FLUSHLOG:000 Flushing count error detection count
POWER:0000000353 Total power-ON time
PWCNT:0000000353 Power-ON count
ADF_JAM:00000 Document jam count in ADF scanning
FB:0000000006 Scanning page count in ADF/document cover/FAX/SCANNER *13
HP_ERR_CODE:XX CIS home positioning error in the document scanner unit *1
HP_LOG1:XXXXXXXX CIS home positioning detection log data in the document scanner unit *1
COMERR1:BF010000 Communications error history (Last 3 errors) *12
BACKUP VER:a Machine information backup file version *1
RESET COUNT:001 Reset count *14
SET UP:20130101
Operation start date of the machine (Current date when the user operates
the machine first after unpacking)
Items shown on the LCD Description

Brother MFC-J5720DW Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Economical printing	Yes
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 2400 DPI
Maximum number of copies	99 copies
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A3 (297 x 420) mm
Output color depth	24 bit
Image formats supported	JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	2400 x 2400 DPI
Faxing	Color faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax resolution (black)	203 x 203 DPI
Fax speed dialing (max numbers)	100
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Email protocols	APOP, IMAP4, POP, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	128-bit WEP, 64-bit WEP, APOP, SMTP-AUTH, SSID, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Ethernet LAN data rates	10, 100 Mbit/s
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Paper input type	Paper tray
Total input capacity	250 sheets
Multi-Purpose tray input capacity	80 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	C5, Com-10, DL, Monarch
Photo paper sizes	9x13, 10x15, 13x18 cm
Paper tray media types	Coated paper, Envelopes, Glossy paper, Matte paper, Photo paper, Plain paper
Paper tray media weight	64 - 120 g/m²
Non-ISO print media sizes	2L, Executive (184 x 267mm), Index card, L, Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B4, B5
Borderless printing media sizes	10x15, 2L, A3, A4, A6, Index card, L, Ledger, Letter
Maximum ISO A-series paper size	A3
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 1.1, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC, MiniSD, MiniSDHC, MMC, MMC Mobile, MMC+, MS Duo, MS Micro (M2), MS PRO Duo, SD, SDHC, SDXC
Sound pressure level (printing)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (ready)	5.5 W
Power consumption (average operating)	32 W
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008 R2 x64, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	Brother ControlCentre\\r NewSoft Presto! PageManager\\r Brother ControlCentre\\r Nuance Paperport 12 SE
Sustainability certificates	Nordic Swan Ecolabel, ENERGY STAR
Package depth	425 mm
Package width	589 mm
Package height	429 mm
Package weight	17800 g
Storage temperature (T-T)	20 - 33 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	345 mm
Width	490 mm
Height	308 mm
