Brother MFC-J5730DW Service Manual

5-7
Confidential
(9) Upon completion of scanning, the machine displays the "Write Head Calib" on the
LCD, creates the head calibration data, and writes it into the flash ROM on the
main PCB.
Upon completion of writing, the "Complete" appears. Press the Stop key to return
to the initial stage of the maintenance mode.
Note: If an error occurs, the machine beeps and displays "Error No **" on the LCD.
Press the Stop key to return to the initial stage of the maintenance mode and
then recover the machine from the error state, following the table given
below. Then go back to step (4).
Error
code
The following error has
occurred.
Do the following:
01
Failed to detect the external
frame.
- Clean the document cover glass.
- Reset the print pattern so that the ▲ mark
is aligned with the left rear of the document
cover without tilt.
- Check that there is no block missing.
- Go back to step (2) and print out "Print
pattern for creating head calibration data"
again.
02
Internal image inclined.
03
Failed to detect position.
04
Failed to write head
calibration data.
- Clean the document cover glass.
- Reset the print pattern so that the ▲ mark
is aligned with the left rear of the document
cover without tilt.
- Check that there is no block missing.
- Restart the machine and perform the
procedure from the beginning again.
- Replace the main PCB.
05
The uneven printing
correction function for upper
and lower ends of the nozzle
is disabled with Maintenance
88.
- Set selector 1 on AMS05 to "0" (ON) in
“1.3.33 Assurance Mode Switch Setting
(Maintenance mode 88)”
in this chapter.
06
Cannot get data due to
memory full.
- Delete fax data and other data stored in the
memory.
- Replace the main PCB.
07
The document scanner unit
is open.
- Close the document scanner unit.
- Reconnect the document scanner sensor
harness.
- Replace the document scanner if the boss
that presses the document scanner sensor
is broken.
- Replace the main PCB.
09
Scanning errors other than
the above.
- Use “1.3.15 Acquisition of White/Black
Level Data (Maintenance mode 55)” in this
chapter.
10
With a media being inserted,
the USB cable or LAN cable
is connected.
- Disconnect the USB cable or LAN cable.
11
The scanner cover is open.
- Close the scanner cover.

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
