Brother MFC-J5730DW Service Manual

5-35
Confidential
1.3.18 Checking of CIS Travel and Specifying of CIS Type (Maintenance mode 59)
< Function >
This procedure allows you to check the movement of the CIS unit integrated in the
document scanner unit.
The CIS unit travels to the three positions – the ADF scanning position, FB scanning
start and end positions.
It also allows you to specify the CIS type into the EEPROM on the main PCB. If you
replace the main PCB, you need to specify the CIS type according to the procedure
given below.
< Operating Procedure >
Check the movement of the CIS unit
(1) Press the 5 and 9 keys in this order in the initial stage of the maintenance mode.
The machine displays the "1:MO 2:CO 3:CHG?" on the LCD.
(2) Press the 1 key.
Duplex scanning models: The "1:FB 2:ADF 3:BTH" appears on the LCD. Press the
1 key.
Simplex scanning models: Go to step (3).
(3) The "1:30 2:60 3:12?" appears on the LCD. Press the 1 key. Press the SET key
repeatedly until the “1: ADF 2: FRT 3: MV” appears on the LCD.
(4) Press the 1 key and then press the SET key to move to the ADF scanning position.
Press the 2 key and then press the SET key to move to the FB scanning start
position.
Press the 3 key and then press the SET key to move to the FB scanning end
position.
(5) To return the machine to the initial stage of the maintenance mode, press the X
key.
Specify the CIS type
(1) Press the 5 and 9 keys in this order in the initial stage of the maintenance mode.
The machine displays the "
1:MO 2:CO 3:CHG?" on the LCD.
(2) Press the 3 key.
Duplex scanning models: The "1:FB 2:ADF?" appears on the LCD.
To specify the type of the first side CIS, press the 1 key; to specify that of the
second side CIS, press the 2 key.
Simplex scanning models: Go to step (3).
(3) The "1:AUTO 2:MANUAL?" appears on the LCD.
(4) Press the 1 key.
The machine automatically sets the CIS type and returns to the initial stage of the
maintenance mode.
If the completion of automatic setting of the CIS type results in mismatch between
the built-in CIS unit and the firmware setting, the "PLS UPDATE PROG" appears
on the LCD. If this happens, load the latest firmware.
Note: If a failure in the automatic setting of the CIS type results in machine error
AF00, press the 2 key in step (3) and specify the CIS type manually. When
“CIS TYPE*
→” is displayed on the LCD (where * indicates the automatically
set CIS type), enter the CIS type (0 or 1).

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
