Brother MFC-J5730DW Service Manual

1-12
Confidential
10 PAPER
10.1 Paper
Paper type and size for each operation
*1
PDF Print is available only for MFC-J5930DW.
*2
Only available for some countries.
Paper weight and thickness
*1
BP71 69 lb (260 g/m
2
) paper is specially designed for Brother inkjet machines.
*2
MFC-J2730DW/J5730DW/J5830DW/J5930DW: Up to 12 mil (Up to 0.3 mm) for MP Tray.
Paper Type Paper Size
Usage
Fax Copy
Direct Print
Printer
JPEG
Print
PDF
Print
*1
Cut-Sheet
Ledger
Letter
A3
A4
Legal
Mexico legal
India legal
Folio
Executive
JIS B4
*2
JIS B5
*2
JIS B6
*2
A5
A6
11 x 17 in. (279.4 x 431.8 mm)
8 1/2 x 11 in. (215.9 x 279.4 mm)
11.7 x 16.5 in. (297 x 420 mm)
8.3 x 11.7 in. (210 x 297 mm)
8 1/2 x 14 in. (215.9 x 355.6 mm)
8.5 x 13.38 in. (215.9 x 339.85 mm)
8.46 x 13.58 in. (215 x 345 mm)
8 1/2 x 13 in. (215.9 x 330.2 mm)
7 1/4 x 10 1/2 in. (184.1 x 266.7 mm)
10.1 x 14.3 in. (257 x 364 mm)
7.2 x 10.1 in. (182 x 257 mm)
5.04 x 7.17 in. (128 x 182 mm)
5.8 x 8.3 in. (148 x 210 mm)
4.1x 5.8 in. (105 x 148 mm)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
---
---
---
---
---
---
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
---
---
---
Yes
Yes
Yes
Yes
Yes
Yes
---
---
---
---
---
---
---
---
---
---
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
---
---
---
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cards
Photo L
Photo 2L
Index Card
4 x 6 in. (10 x 15 cm)
3 1/2 x 5 in. (9 x 13 cm)
5 x 7 in. (13 x 18 cm)
5 x 8 in. (13 x 20 cm)
---
---
---
---
Yes
---
---
---
Yes
---
Yes
--
---
---
---
---
Yes
Yes
Yes
Yes
Envelopes
C5 Envelope
DL Envelope
Com-10
Monarch
6.4 x 9 in. (162 x 229 mm)
4.3 x 8.7 in. (110 x 220 mm)
4 1/8 x 9 1/2 in. (104.7 x 241.3 mm)
3 7/8 x 7 1/2 in. (98.4 x 190.5 mm)
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Yes
Yes
Yes
Yes
Paper Type Weight Thickness
Cut-Sheet
Plain Paper, Recycled Paper 17 to 32 lb (64 to 120 g/m
2
) 3 to 6 mil (0.08 to 0.15 mm)
Inkjet Paper 17 to 53 lb (64 to 200 g/m
2
) 3 to 10 mil (0.08 to 0.25 mm)
Glossy Paper
*1,2
Up to 58 lb (Up to 220 g/m
2
) Up to 10 mil (Up to 0.25 mm)
Cards
Photo Card
*1,2
Up to 58 lb (Up to 220 g/m
2
) Up to 10 mil (Up to 0.25 mm)
Index Card Up to 32 lb (Up to 120 g/m
2
) Up to 6 mil (Up to 0.15 mm)
Envelopes 20 to 25 lb (80 to 95 g/m
2
) Up to 20 mil (Up to 0.52 mm)

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
